PRO 63
CARDIOID DYNAMIC MICROPHONE
• Ideal for musical instrument pickup and general use
• Hi-ENERGY ® neodymium magnet for improved output and
transient response
• Two-stage screen reduces wind noise and "popping" during close
use
• Corrosion-resistant contacts from gold-plated XLRM-type
connectors
• Tailored response provides natural, full-range reproduction
• Rugged design and construction for reliable performance
• Cardioid polar pattern reduces pickup of sounds from the sides
and rear, improving isolation of desired sound source
Output from the microphone's XLRM-type connector is low
impedance (Lo-Z) balanced. The signal appears across Pins 2 and
3; Pin 1 is ground (shield). Output phase is "Pin 2 hot" – positive
acoustic pressure produces positive voltage at Pin 2.
Plug Type Ground
XLR Pin 1
1 / " "TRS" Sleeve
4
/ " Sleeve
1
4
To avoid phase cancellation and poor sound, all mic cables must be
wired consistently: Pin 1-to-Pin 1, etc. For a high-impedance (Hi-Z)
mic input, connect a Lo-Z balanced cable to a Hi-Z matching
transformer (A-T CP8201 or equal) at the equipment input.
When using the PRO 63 in settings with a stage monitor speaker,
the speaker should be located 180° off axis (at the rear of the
microphone). This placement, in conjunction with the microphone's
uniform cardioid pickup pattern, will virtually eliminate the possibility
of undesired audio feedback.
Take care to keep foreign particles from entering the windscreen.
An accumulation of iron or steel filings on the diaphragm, and/or
foreign material in the windscreen's mesh surface, can degrade
performance.
Audio "+" Audio "–"
Pin 2 Pin 3
Tip Ring
Tip Sleeve
PRO 63 SPECIFICATIONS †
ELEMENT
POLAR PATTERN
FREQUENCY RESPONSE
OPEN CIRCUIT SENSITIVITY
IMPEDANCE
WEIGHT (less cable and accessories)
DIMENSIONS
OUTPUT CONNECTOR
CABLE
ACCESSORIES FURNISHED
† In the interest of standards development, A.T .U.S. offers full details on its test
methods to other industry professionals on request.
*1 Pascal = 10 dynes /cm 2 = 10 microbars = 94 dB SPL
Specifications are subject to change without notice.
Polar Pattern
0
330 30
300 60
270 90
240 120
50 100
210 150
180
LEGEND
SCALE IS 5 DECIBELS PER DIVISION
LEGEND
200 Hz
1 kHz
5 kHz
8 kHz
Audio-Technica U.S., Inc., 1221 Commerce Drive, Stow, Ohio 44224
Audio-Technica Limited, Old Lane, Leeds LS11 8AG England
www.audio-technica.com
P3893-00210 P51683-EN ©2004 Audio-Technica U.S., Inc.
Dynamic
Cardioid
70-16,000 Hz
–55 dB (1.7 mV) re 1V at 1 Pa*
300 ohms
10.9 oz (309 g)
7.17" (182.1 mm) long,
1.63" (41.4 mm) head diameter
Integral 3-pin XLRM-type
15.0' (4.5 m) cable with XLRF-type
connector at microphone end,
XLRM-type connector at equipment
end
AT8470 Quiet-Flex ™ stand clamp for
5 / "-27 threaded stands;
8
5 / "-27 to 3 / "-16 threaded adapter;
8 8
soft protective pouch
Frequency Response
200 500 1k 2k 5k 10k 20k
Frequency in Hertz
12" or more on axis
Printed in Taiwan
10 dB
