Fig 1. Rivet Nut Tool
1 993/68101 Slide Hammer
2 993/68102 End Stops
3 993/68103 Adaptor - M20 x 5/8" UNF
4 993/68104 Adaptor - M20 x 1" UNF
5 993/68105 Adaptor - M20 x M20
6 993/68106 Adaptor - M20 x M24
1-5-5
Section 1-5 - General Information

Tool Detail Reference

1 826/01099
826/01101
826/01102
826/01103
826/01104
826/01105A M10 x 26 mm Rivet Nut
2 -
Fig 2. 993/68100 Slide Hammer Kit
7 993/68107
8 993/68108
9 993/68109
10 993/68110
11 993/68111
9803/3750-05 (1-06-00)
Service Tools
Tool Detail Reference
M6 x 16 mm Rivet Nut
M6 x 19 mm Rivet Nut
M8 x 18 mm Rivet Nut
M8 x 21 mm Rivet Nut
M10 x 23 mm Rivet Nut
Installation Tool available from: Bollhoff
Fastenings Ltd (www.bollhof.com)
Bar - M20 x M20 X 800 mm
Adaptor - M20 x 7/8" UNF
Adaptor - M20 x M12
Adaptor - M20 x 5/8" UNF (Shoulder)
Adaptor - M20 x 1/2" UNF
