Option module for PolluTherm
4. Modbus data register list
Designation Modbus
Register
Firmware 30001 or 40001
Version 2
Energy 30002 or 40002
Energy 30004 or 40004
(Unit factor)
Energy (Unit) 30005 or 40005
Energy (Float) 30007 or 40007
Volume 30009 or 40009
Volume 30011 or 40011
(Unit factor)
Volume (Unit) 30012 or 40012
Volume (Float) 30014 or 40014
Flow 30016 or 40016
Flow 30018 or 40018
(Unit factor)
Flow (Unit) 30019 or 40019
Flow (Float) 30021 or 40021
Power 30023 or 40023
Power 30025 or 40025
(Unit factor)
Power (Unit) 30026 or 40026
Power (Float) 30028 or 40028
Inlet 30030 or 40030
temperature
(Fixed)
Inlet 30031 or 40031
temperature
(Float)
Outlet 30033 or 40033
temperature
(Fixed)
Outlet 30034 or 40034
temperature
(Float)
Temperature 30036 or 40036
difference
(Fixed)
Temperature 30038 or 40038
difference
(Float)
Tariff Energy 30040 or 40040
Tariff Energy 30042 or 40042
(Unit factor)
Tariff Energy 30043 or 40043
(Unit)
Tariff Energy 30045 or 40045
(Float)
Cooling Energy 30047 or 40047
Cooling Energy 30049 or 40049
(Unit factor)
Cooling Energy 30050 or 40050
(Unit)
Cooling Energy 30052 or 40052
(Float)
Fabrication 30054 or 40054
Number
Modbus Modbus
Register Type Address
Input or Holding 0
Input or Holding 1
Input or Holding 3
Input or Holding 4
Input or Holding 6
Input or Holding 8
Input or Holding 10
Input or Holding 11
Input or Holding 13
Input or Holding 15
Input or Holding 17
Input or Holding 18
Input or Holding 20
Input or Holding 22
Input or Holding 24
Input or Holding 25
Input or Holding 27
Input or Holding 29
Input or Holding 30
Input or Holding 32
Input or Holding 33
Input or Holding 35
Input or Holding 37
Input or Holding 39
Input or Holding 41
Input or Holding 42
Input or Holding 44
Input or Holding 46
Input or Holding 48
Input or Holding 49
Input or Holding 51
Input or Holding 53
1
Data Value Unit
Range
Uint16 -
Int32
UInt16
kWh, MWh,
MJ, GJ
4 char ASCII
IEEE754
Int32
UInt16
l (dm 3 ), m 3
4 char ASCII
IEEE754
Int32
UInt16
l/h, m 3 /h
4 char ASCII
IEEE754
Int32
UInt16
W, kW
4 char ASCII
IEEE754
Int16 0.01°C
IEEE754 °C
Int16 0.01°C
IEEE754 °C
Int32 0.001°C
IEEE754 °C
Int32
UInt16
kWh, MWh,
4 char ASCII
MJ, GJ
IEEE754
Int32
UInt16
kWh, MWh,
4 char ASCII
MJ, GJ
IEEE754
Int32 -
M H 6123 INT, page 3
Read only (RO)
Read/write (R/W)
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
RO
