ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
TGS27SH-CS01
2
TGS27SH-CS02
3
62TGS27SHY101
You will need the following tools:
-Phillips Screwdriver (Not included)
-Hex.Key Wrench
Attention:
Make sure that each bolt needed for all steps
matches the corresponding figure to ensure proper
assembly.

Step 1:

Place the table top (#1) onto a non-abrasive
surface, such as a carpet, with its underside
facing upwards. Insert the legs (#2) into the plastic
holders attached on the underside of the table top
(#1) rim. See Figure 1.
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely
!
assembled.
Do not sit or stand on this table.
!
Do not discard of any of the packaging until you have checked that you have all of the
!
parts and fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed
!
by children. Children should always be under direct adult supervision while using this product.
! Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
TGS27SH-
PART Q'TY
TABLE TOP
LEG
CENTER CONNECTOR
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
WM
4
17C17A0403001Y4
1 5
17C01A0706002Y4
4
6
17FA05040301-Y4
7
1
18000337002
FIGURE 1
2
SCREW ST4.2*12
BOLT M6*16
WASHER d6.5*D13*1.0
BOLT CAP M6
2
2
2
1
