- Page 1 VAPO GRILL ELECTRICAL HEATED TYPE: GT1, GT2, GT3, GT6 Installation and Operation Manual S/N: Rev.: 2.0...
- Page 3 Dear Customer, Congratulations on deciding to choose a Metos appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied Metos customer like thousands of customers we have around the world.
- Page 4 20.9.2002 Rev. 2.0...
-
Page 5: Table Of Contents
20.9.2002 Rev. 1. General ......................1 1.1 Symbols used in the manual ..................1 1.2 Symbols used on the appliance ..................1 1.3 Checking the relationship of the appliance and the manual .......... 2 2. Safety ......................3 2.1 Safe use of the appliance ....................3 2.2 Safety instructions in case of malfunction .............. - Page 6 20.9.2002 Rev.
-
Page 7: General
20.9.2002 Rev. 2.0 General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations. -
Page 8: Checking The Relationship Of The Appliance And The Manual
20.9.2002 Rev. 2.0 General 1.3 Checking the relationship of the appliance and the manual The rating plate of the appliance indicates the serial number of the appliance. If the man- uals are missing, it is possible to order new ones from the manufacturer or the local rep- resentative. -
Page 9: Safety
20.9.2002 Rev. 2.0 Safety 2. Safety 2.1 Safe use of the appliance The grill can be used only by staff trained to use the appliance. Never leave the grill on without supervision. Never immerse the grill in water. Never touch the grill heating elements when the applience is working. Never leave paper or textile on the grill heating elements. -
Page 10: Safety Instructions In Case Of Malfunction
20.9.2002 Rev. 2.0 Safety 2.2 Safety instructions in case of malfunction In the event of fault or malfunction, switch the power off. Call service. -
Page 11: Functional Description
20.9.2002 Rev. 2.0 Functional description 3. Functional description 3.1 Application of the appliance The grill is intended for frying raw materials direct on the grill heating elements. 3.1.1 Prohibited use The grill is not designed for heating kettles and pans like on an electric range. 3.2 Operating principle It is important that the water tank is filled with water (appr. -
Page 12: Tips
20.9.2002 Rev. 2.0 Functional description The Vapo Grill is saving energy mainly because the appliance never has to be in a stand- by position. The appliance is at operating temperature after 2 minutes. Longer preheating is not necessary. 3.2.1 Tips Not only meat, but also crustacea, fish and bread can be prepared to delicious, original dishes on your Vapo Grill. - Page 13 20.9.2002 Rev. 2.0 Functional description Pepper and salt can be added to the same solution. Spice the meat with a small brush in one movement. Do preferably not use any oil for the taste. C. Method for fish up to 500 g For fillet of salmon as well as tunny-fish, trout and all sorts of solid fish, one uses a sauce of melted butter, a dash of white wine, the juice of 1 lemon, mixed with grill herbes, pep- per and salt.
- Page 14 20.9.2002 Rev. 2.0 Functional description DISHES WEIGHT POSITION TIME METHOD REMARK. lambsleg 1250 g 15’+45’ Medium sausage 100 g 10’ hamburger 150 g 7’ Poultry-spring chick 450 g 15’ quial 5’ Grilling bread Toast 30’ turn quickly...
-
Page 15: Operation Instructions
20.9.2002 Rev. 2.0 Operation instructions 4. Operation instructions 4.1 Before using the appliance 4.1.1 Preparing the operation Before starting to use the Vapo Grill definetively, it is recommended to switch it on to po- sition 2 for 15 minutes without any dishes on it. With the combinated switching and regulating knob the grill can be easily switched on and each heating element can be regulated steplessly. - Page 16 20.9.2002 Rev. 2.0 Operation instructions The water tank is made of heavy enammeled steelplate, easy to clean and suitable for any type of dishwashing machine. To remove the water tank, turn off the grill heating element and leave it in its vertical po- sition.
-
Page 17: Installation
20.9.2002 Rev. 2.0 Installation 5. Installation 5.1 Positioning the appliance Put the appliance on a solid table and make sure it stays straight. 5.2 Electrical connections Make sure that the supply voltage corresponds to the one on the rating plate at the bottom of your appliance. -
Page 18: Troubleshooting
20.9.2002 Rev. 2.0 Troubleshooting 6. Troubleshooting If your grill doesn’t work, check the following: • is the plug well plugged in • are the fuses in the supply line in order • is the main switch on If the above mentioned methods don’t help, call service. -
Page 19: Technical Specifications
20.9.2002 Rev. 2.0 Technical specifications 8. Technical specifications Connection and main electrical wiring diagram... - Page 20 20.9.2002 Rev. 2.0 Technical specifications Connection and main electrical wiring diagram...
- Page 21 20.9.2002 Rev. 2.0 Technical specifications Item Type Specification Dimensions (L x W x H) 270 x 545 x 130 Dimensions (L x W x H) 435 x 545 x 130 Dimensions (L x W x H) 600 x 545 x 130 Dimensions (L x W x H) 950 x 635 x 297 Grill surface mm...
