MaxxMar Cool Motion Operation & Programming Instructions

1and 5 Channel Remote Control Specifications
(Models: RC-215, RC-230)
Transmission power: 10dBm
ASK 433.92MHz wireless transmission
Outdoor transmission distance: 200m
Indoor transmission distance: 35m
Working temperature: -20°C- +55°C
Battery model: CR2450
Basic Operation - 1 and 5 Channel Remote Controls
Command Key Combination
Press UP
Go Up
Press DOWN
Go Down
Stop Press STOP
Step Up Press LEFT
Press RIGHT
Step Down
Hold LEFT
Go to Favourite
Position #1 for 2 seconds
Go to Favourite
Hold RIGHT
Position #2
for 2 seconds
Next
Press
2
Channel
CHANNEL
1. The motor will stop on button release if the limit is not yet set.
2. This command is not sent to the motor, and affects only the remote control on which it is executed.
New Generation Maxx Motors
Cool Motion, Domlux, HWM-10, HWM-20
Operation & Programming Instructions
Description
Move all the way to the upper
1
limit
Move all the way to the lower
1
limit
Stop ongoing motion
Move the motor up in a small
increments
Move the motor up in a small
increments
Move the motor to favourite
position number 1.
Move the motor to favourite
position number 2.
Cycle to the next channel (or
group of channels) on the
remote, making it active.
Illustration
Note:
Unless noted, all commands are sent
from a remote control to a motor, and
will only have effect if the remote
control's active channel has been
paired with the desired motor.
