MOTORIZATION
INSTRUCTION GUIDE
ORIGINAL GENERATION
MAXX MOTOR
Table of Contents
Safety Guidelines - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2
Solo A-1- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3
Cool Motion & Domlux- - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5
Cool Motion Rechargeable Bluetooth Battery Motor- - - - - - - - - 7
Cellular Shades- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9
MaxxLink & Home Automation- - - - - - - - - - - - - - - - - - - - - - -12
MAXXMAR WINDOW FASHIONS
150 Bartor Road, Toronto, Ontario M9M 1H1
Tel: 416-742-6299 - Toll Free: 1-866-916-6299 - Fax: 416-742-1772
www.maxxmar.com
MADE IN CANADA
100
%
MISE EN GARDE
WARNING
RISQUE D'ÉTRANGLEMENT
STRANGULATION HAZARD
Les enfants en bas âge peuvent s'étrangler avec des cordes. Enlevez
Young children can be strangled by cords. Immediately remove
immédiatement ce produit si une corde mesurant plus de 22 cm devient
this product if a cord longer than 22 cm or a loop exceeding
accessible ou si le contour d'une boucle de plus de 44 cm devient accessible.
44 cm around becomes accessible.
Advertisement
Table of Contents
Related Manuals for MaxxMar MAXX
Summary of Contents for MaxxMar MAXX
-
Page 1: Table Of Contents
INSTRUCTION GUIDE ORIGINAL GENERATION MAXX MOTOR Table of Contents Safety Guidelines - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 Solo A-1- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 Cool Motion &... -
Page 2: Safety Guidelines
Motorization Safety Guidelines IMPORTANT Motorization Cords & Wires Installation & Usage Guidelines Upon installation of any motorized products, wiring/cords must be covered, stapled or concealed. This installation rule must be followed at all times. All wiring/cords must fall in compliance with the warning stated below. -
Page 3: Solo A-1
Maxx Motor Original Generation Solo-A1 Operation & Programming Instructions Maxx Motor Original Solo-A1 (without Bluetooth) Rechargeable Wand Control System with Internal Battery Motor 12V DC with Battery Charger Motor Unit Assembling - Hang switch wand hanger with motor adapter - Connect switch wand cable pin to the motor Battery Charging - Charging motor battery: use a DC5V plug charger... - Page 4 Solo A1: Basic Operation and Troubleshooting Continued Key Combination Command Item Description Illustration Motor goes up Press UP button Press STOP button when close Motor stops Upper to the upper limit Limit position Setting Press UP or DOWN button to adjust the final position Motor sounds DI once: upper Press button once at...
-
Page 5: Cool Motion & Domlux
Maxx Motor Original Generation Domlux & Cool Motion Operation & Programming Instructions Specifications Motor Load Torque: 0.7Nm/34rpm, 1.1Nm/25rpm, 2Nm/28rpm Battery: Li-ion Battery, 2000mAH, 7.4V. Note: The side of motor head with SETTING button should face towards you (towards the outside). Motor antenna should be as straight as possible in the position far away from metal objects. - Page 6 Domlux & Cool Motion: Basic Operation and Troubleshooting Continued Command Item Key Combination Description Illustration Press UP button on Motor runs up transmitter Press STOP button when motor gets Motor stops close to end-point of Setting upper limit Upper Motor runs step by step to adjust Limit Press either UP or upper limit accurately...
-
Page 7: Cool Motion Rechargeable Bluetooth Battery Motor
Maxx Motor Original Generation Cool Motion Rechargeable Bluetooth Battery Motor Operation & Programming Instructions Specifications Motor Load Torque: 1.1Nm / Speed: 28rpm Battery: DC7.4V/2000mAH Note: The side of motor head with SETTING button should face towards you (towards the outside). Motor antenna should be as straight as possible in the position far away from metal objects. - Page 8 Cool Motion Rechargeable Bluetooth Battery Motor: Basic Operation & Troubleshooting Continued Key Combination Command Item Description Illustration Press UP button on Motor runs up transmitter Press STOP button when motor gets Motor stops close to end-point of Setting upper limit Upper Motor runs step by step to adjust Limit Press either UP or...
-
Page 9: Cellular Shades
Maxx Motor Original Generation Cellular Shades Operation & Programming Instructions Specifications Motor Load Torque: 0.7Nm/34rpm, 1.1Nm/25rpm, 2Nm/28rpm Battery: Li-ion Battery, 2000mAH, 7.4V. Note: The side of motor head with SETTING button should face towards you (towards the outside). Motor antenna should be as straight as possible in the position far away from metal objects. - Page 10 Cellular Shades: Basic Operation & Troubleshooting Continued Command Item Key Combination Illustration Description Press UP button on Motor runs up transmitter Press STOP button when motor gets Motor stops close to end-point of Setting upper limit Upper Motor runs step by step to adjust Limit Press either UP or uppper limit accurately...
-
Page 11: Solar Panel & Window Application Tables & Guidelines
Motorization Solar Panel & Window Application Tables & Guidelines Solar Panel Normal Operation After commissioning, the battery is trickle-charged by electrical energy generated by the solar panel. The energy is stored in the high capacity NiMH battery (acting like a reservoir) and the system provides uninterrupted service through many climatic seasons. It is normal for the battery to gain more energy summer as compared to winter- the Solar Panel converts the intensity of light to energy upon availability. -
Page 12: Maxxlink & Home Automation
• A smartphone or tablet running Android 5.0 (Lollipop) or higher, or lOS 8 or higher is needed. MaxxLink Status: Original Maxx Motor Code for MaxxLink: M6707 Getting to know your MaxxLink 1. Download the Neo Smart Blinds app Download the app to your phone or tablet by searching Neo Smart Blinds on Google Play or the App Store.
