MaxxMar Maxx Motor HWM-10 Installation, Operation & Programming Instructions

Advertisement

MOTORIZATION
INSTRUCTION GUIDE
NEW GENERATION
MAXX MOTOR

Table of Contents

Safety Guidelines - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2
Solo A-1- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3
Cool Motion & Domlux, HWM-10 & HWM-20- - - - - - - - - - - - - 6
2" Wood & Faux Wood Horizontal Blinds- - - - - - - - - - - - - - - 14
Solar Panel - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -18
Wall Remote Control Systems- - - - - - - - - - - - - - - - - - - - - - -19
MaxxLink & Home Automation- - - - - - - - - - - - - - - - - - - - - - -25
Bluetooth- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -26
MAXXMAR WINDOW FASHIONS
150 Bartor Road, Toronto, Ontario M9M 1H1
Tel: 416-742-6299 - Toll Free: 1-866-916-6299 - Fax: 416-742-1772
www.maxxmar.com
MADE IN CANADA
100
%
MISE EN GARDE
WARNING
RISQUE D'ÉTRANGLEMENT
STRANGULATION HAZARD
Les enfants en bas âge peuvent s'étrangler avec des cordes. Enlevez
Young children can be strangled by cords. Immediately remove
immédiatement ce produit si une corde mesurant plus de 22 cm devient
this product if a cord longer than 22 cm or a loop exceeding
accessible ou si le contour d'une boucle de plus de 44 cm devient accessible.
44 cm around becomes accessible.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Maxx Motor HWM-10 and is the answer not in the manual?

Questions and answers

Paul Harrington
February 22, 2025

How can I control my 6 max mar roller blinds individually from one remote

1 comments:
Mr. Anderson
February 22, 2025

You can control 6 MaxxMar roller blinds individually using one remote for the Maxx Motor HWM-10 by assigning each blind to a separate channel on a 15 or 30-channel remote (Models: RC-215, RC-230). Follow these steps:

1. Assign Each Blind to a Channel
- Use the remote to select a channel (e.g., Channel 1 for Blind 1, Channel 2 for Blind 2, etc.).
- Pair each blind with its designated channel by following the motor pairing instructions.

2. Operate Each Blind Separately
- Select the desired channel on the remote.
- Use the UP, DOWN, and STOP buttons to control the blind.

3. Set Limits and Favorite Positions (Optional)
- Use the SETTING button to set upper and lower limits.
- Save a favorite position by adjusting the blind and pressing the required combination.

By assigning each blind to a dedicated channel, you can control them individually using a single remote.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for MaxxMar Maxx Motor HWM-10

  • Page 1: Table Of Contents

    Bluetooth- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -26 MAXXMAR WINDOW FASHIONS...
  • Page 2: Safety Guidelines

    Motorization Safety Guidelines IMPORTANT Motorization Cords & Wires Installation & Usage Guidelines Upon installation of any motorized products, wiring/cords must be covered, stapled or concealed. This installation rule must be followed at all times. All wiring/cords must fall in compliance with the warning stated below.
  • Page 3: Solo A-1

    Maxx Motor New Generation Solo-A1 Operation & Programming Instructions Maxx Motor New Generation Solo-A1 (with Bluetooth) Rechargeable Wand Control System with Internal Battery Motor 12V DC with Battery Charger Battery Charging - Plug the micro USB cable into the charging port located at the bottom of the wand - Please recharge motor battery when motor alarm sounds off (DI, DI-DI) or motor begins to falter...
  • Page 4 Solo-A1: Basic Operation & Troubleshooting Continued Key Combination Command Item Description Illustration Press the OPERATION button The blind will jog up and down on back of wand for 5 seconds Keep pressing until the blind Press the DOWN reaches the lower limit button on the wand Press and release The blind will jog: this sets the Setting...
  • Page 5 Solo-A1: Basic Operation & Troubleshooting Continued Command Item Key Combination Illustration Description Note: Once the upper and lower limits are set, the motor can store two favourite positions. After setting the favourite positions, double press the UP or DOWN button to send the motor to favourite position 1 or 2. If you also use the Neo Smart Blinds Blue App the bottom of this page first.
  • Page 6: Cool Motion & Domlux, Hwm-10 & Hwm-20

    Maxx Motor New Generation Cool Motion, Domlux, HWM-10, HWM-20 Operation & Programming Instructions 1 and 5 Channel Remote Control Specifications (Models: RC-215, RC-230) Transmission power: 10dBm ASK 433.92MHz wireless transmission Outdoor transmission distance: 200m Indoor transmission distance: 35m Working temperature: -20°C- +55°C Battery model: CR2450 Cool Motion, Domlux, HWM-10, HWM-20: Basic Operation - 1 &...
  • Page 7 Cool Motion, Domlux, HWM-10, HWM-20: Basic Operation - 1 & 5 Channel Remote Controls Cont’d Command Item Key Combination Description Illustration In order for a remote control to execute commands on a motor, its active channel must be paired with that motor. Use the instructions below to choose a channel, then proceed to the pairing process.
  • Page 8 Cool Motion, Domlux, HWM-10, HWM-20: Basic Operation - 1 & 5 Channel Remote Controls Cont’d Command Item Key Combination Illustration Description Setting or Adjusting Limits The motor’s upper and lower rotational limits are set individually. Don’t forget to always select the correct channel of the motor you want to adjust. Hold the SET + UP The motor will move up and down to indicate the process...
  • Page 9 Cool Motion, Domlux, HWM-10, HWM-20: Basic Operation - 1 & 5 Channel Remote Controls Cont’d Command Item Key Combination Description Illustration Note: Once the upper and lower limits are set, the motor can store two favourite positions. After setting the fa- vourite positions, hold the LEFT or RIGHT button to send the motor to favourite position 1 or 2.
  • Page 10 New Generation Cool Motion, Domlux, HWM-10, HWM-20 15 and 30 Channel Remote Control Specifications (Models: RC-215, RC-230) Transmission power: 10dBm ASK 433.92MHz wireless transmission Outdoor transmission distance: 200m Indoor transmission distance: 35m Working temperature: -20°C- +55°C Battery model: CR2450 Cool Motion, Domlux, HWM-10, HWM-20: Basic Operation - 15 & 30 Channel Remote Controls Key Combination Description Illustration...
  • Page 11 Cool Motion, Domlux, HWM-10, HWM-20: Basic Operation - 15 & 30 Channel Remote Controls Cont’d Command Item Key Combination Illustration Description In order for a remote control to execute commands on a motor, its active channel must be paired with that motor. Use the instructions below to choose a channel, then proceed to the pairing process.
  • Page 12 Cool Motion, Domlux, HWM-10, HWM-20: Basic Operation - 15 & 30 Channel Remote Controls Cont’d Command Item Key Combination Description Illustration Setting or Adjusting Limits The motor’s upper and lower rotational limits are set individually. Don’t forget to always select the correct channel of the motor you want to adjust. The motor will move up and Hold the SET &...
  • Page 13 Cool Motion, Domlux, HWM-10, HWM-20: Basic Operation - 15 & 30 Channel Remote Controls Cont’d Command Item Key Combination Description Illustration Note: Once the upper and lower limits are set, the motor can store two favourite positions. After setting the favourite positions, hold the LEFT or RIGHT button to send the motor to favourite position 1 or 2.
  • Page 14: 2" Wood & Faux Wood Horizontal Blinds

    Maxx Motor New Generation 2” Wood & Faux Wood Horizontal Blinds Operation & Programming Instructions Specifications: Remote Control Models: RC201, RC202 & RC206 Note: Remote Controls RC215 & RC230 can also be used. Description: 40 mm RF motor, double shaft, 40dB. Radio Frequency (RF): 433.92 MHz.
  • Page 15 2” Wood & Faux Wood Horizontal Blinds - Basic Operation & Troubleshooting Continued Key Combination Command Item Description Illustration In order for a remote control to execute commands on a motor, its active channel must be paired with that motor. Use the instructions below to choose a channel, then proceed to the pairing process.
  • Page 16 2” Wood & Faux Wood Horizontal Blinds - Basic Operation & Troubleshooting Continued Key Combination Command Item Description Illustration Setting or Adjusting Limits The motor’s upper and lower rotational limits are set individually. Don’t forget to always select the correct channel of the motor you want to adjust. The motor will move up and Hold the SET + UP down to indicate the process...
  • Page 17 2” Wood & Faux Wood Horizontal Blinds - Basic Operation & Troubleshooting Continued Command Item Key Combination Illustration Description Note: Once the upper and lower limits are set, the motor can store two favourite positions. After setting the favourite positions, hold the LEFT or RIGHT button to send the motor to favourite position 1 or 2. If you also use the Neo Smart Blinds app or the Neo Smart Blinds Blue app to control your blinds, please read the related topic in the bottom of this page first.
  • Page 18: Solar Panel

    Motorization Solar Panel & Window Application Tables & Guidelines Solar Panel Normal Operation After commissioning, the battery is trickle-charged by electrical energy generated by the solar panel. The energy is stored in the high capacity NiMH battery (acting like a reservoir) and the system provides uninterrupted service through many climatic seasons. It is normal for the battery to gain more energy summer as compared to winter- the Solar Panel converts the intensity of light to energy upon availability.
  • Page 19: Wall Remote Control Systems

    Maxx Motor New Generation Wall Remote Control Systems Operation & Programming Instructions Wall Remote Control - Version 1 - Model WS-202 (2 channels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
  • Page 20 Wall Remote Control - Version 1 - Model WS-202 (2 channels) cont’d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
  • Page 21 Wall Remote Control - Version 1 - Model WS-204-W (4 channels) !"#$%&'()%$(**+$ !"#$%"&'(")%'*&+#,-'.%"/'0#(123%3')-+#4'' (")%'52"#3'"%'$0*&3$6'7"+83'8"//0#,-'0%3' 090+&0*&3'+.'+#$34%0$3,'1+$2':/0;"#':&3<0=' >""4&3':--+-$0#$'"%'?+%+'?2"%$)8$-6 R($%-#$("1+(-#()#3(0+#.(1(+6E'/#,-6"/&#0&6"I# 3(0+#*Q("'#(+#1%,-'14#='1#&$Q'/0-'&#1(#%01(J .%1'#3(0+#Q(.'4#S(#"''/#1(#$(""'$1#1(#3(0+#...
  • Page 22 Wall Remote Control - Version 1 - Model WS-204-W (4 channels) cont’d D'#)&(2$& !" #$%" ,'..$%6'")1"C&,2+""$#&+(&(2$& -'('.&01##&-'8$&('&1")1,+($&(2$& #1-1(%&2+8$&B$$"&)$#$($)3 !" !"#"$"%&##%'"()$"%*)+$')#, & !"#$%!&'()*+,'*!+(*%!-("!+*.*"*!,&&*'!/-+! 1")181):+##93 -.%0(.+!"#*!/01! !" 1(2*%!"(!$-+$)/"*!"#*!&'()*%%! D'#)&(2$& !" !" !" ,'..$%6'")1"C&,2+""$#&+(&(2$& -'('.&01##&-'8$&('&1")1,+($&(2$& 2.%0(.+!"#*!/01! 6.',$%%&('&%$(&:6&(2$&:66$.&#1-1(& 2+%&%(+.($)3 1(2*%!"(!$-+$)/"*!"#/"!"#*!/..! &/$'*+!'*1("*!)(-"'(.%!3*'*! #" !%$&!"*&#$%"&+")& <.$%%& B$$"&%+8$)3 D'#)&(2$&...
  • Page 23 Wall Remote Control - Version 2 - Model WS-208 (8 channels) !"#$%&'()%$(**+$ !"#$%"&'(")%'*&+#,-'.%"/'0#(123%3')-+#4'' (")%'52"#3'"%'$0*&3$6'7"+83'8"//0#,-'0%3' 090+&0*&3'+.'+#$34%0$3,'1+$2':/0;"#':&3<0=' >""4&3':--+-$0#$'"%'?+%+'?2"%$)8$-6 R($%-#$("1+(-#()#3(0+#.(1(+6E'/#,-6"/&#0&6"I# 3(0+#*Q("'#(+#1%,-'14#='1#&$Q'/0-'&#1(#%01(J .%1'#3(0+#Q(.'4#S(#"''/#1(#$(""'$1#1(#3(0+#...
  • Page 24 Wall Remote Control - Version 2 - Model WS-208 (8 channels) cont’d...
  • Page 25: Maxxlink & Home Automation

    Motorization MaxxLink and Home Automation MaxxLink Control your blinds from anywhere using your phone or tablet. Voice commands are available if Integrated with Amazon Alexa or Google Home (Google Assistant). System requirements • A strong WiFi signal (3 bars or more) in the location where you will setup your Smart Controller.
  • Page 26: Bluetooth

    Motorization Bluetooth How to setup a blind? First, download the Blue Link app to your device using one of the buttons below: For each motorized blind, add the Neo Blue Link to the motor using the Neo Blue Link connector. You may need to use a chair or a ladder to be able to reach the connection wire. If that is the case, you should remain on the chair/ladder until the end of the claim process.
