QUICK START GUIDE: YSI Pro ODO
This guide serves as a quick reference
for operating a YSI Pro ODO. It is for
your convenience & not intended to
replace the full-length manual where
additional information may be found.
Figure 1: Clockwise from bottom left
- Grey transport sleeve, silver sensor
guard, sensor, ODO handset
Van Walt Ltd | Prestwick Lane | Grayswood | Haslemere | Surrey | GU27 2DU | Tel. 01428 661 660 | Fax. 01428 656 808 | www.vanwalt.com
RR172V2_07/06/2019_MS-N
Important:
• Sensor caps must never run dry. Please always store the sensor in the grey storage
sleeve when not in use, after dampening the sponge in the storage sleeve.
• Please treat the optical lens with great care - do not touch without wearing
surgical gloves, clean only with lens cleaning cloth.
Setting-up your ODO
1. Attach the cable to the YSI meter.
2. Remove storage sleeve from sensor.
3. Ensure sensor guard is connected correctly and gently lower the sensor end of
the cable to required height in the well.
4. Hold green button for 3 seconds to turn On/Off meter.
5. PROBE -> DISPLAY to show desired sensor readings on screen.
Logging
1. FILE -> SITE LIST -> ADD NEW to create personal site.
2. SYSTEM -> LOGGING -> CONTINUOUS MODE to begin automatic interval logging.
3. ENTER to begin logging (from normal run screen).
4. SITE in drop down menu to select your personal site.
5. ENTER to stop logging.
6. FILE -> VIEW DATA to view data.
