QUICK START GUIDE: GA5000 Portable Landfill Gas Analyser
This guide serves as a quick reference
for operating a GA5000 Portable
Landfill Gas Analyser. It is for your
convenience & not intended to
replace the full-length manual where
additional information may be found.
Van Walt Ltd | Prestwick Lane | Grayswood | Haslemere | Surrey | GU27 2DU | Tel. 01428 661 660 | Fax. 01428 656 808 | www.vanwalt.com
RR207V3_08/06/2018_JI
This unit was dispatched serviced, calibrated & with everything you need to operate it.
1. To switch the instrument on, hold the 'On/Off' key. The instrument will start-up & run
through a test procedure.
2. Always use tubing provided to stop moisture ingress into the instrument.
3. Start by doing a quick 'self-purge' test by following the on-screen instructions.
4. Press 'Start' key which will take you through all the settings.
For one well you have Gas Analysis, Pressure & Flow Readings
Scan to download the video
+44 (0)1428 661 660
A - Main Gas Read Screen
B - Soft-keys
C - Backlight Key
D - Menu Key
E - Key 2 – Page Up
F - Key 4 – Scroll Left
G - Pump Key
H - LED Light
I - On/Off (Start) Key
J - Assistance Key
K - Key 6 – Scroll Right
L - Key 8 – Page Down
M - Enter Key
N - General Keys
