Opitec Asteroid OPI13 Quick Start Manual

L E D b a l l " A s t e r o i d O P I 1 3 "
Parts List
Wooden block
Welding rod
Rainbow-LED
Button cell 3V
Nylon Wire
Table tennis ball
E113923#2
113.923
The OPITEC range of projects is not intended as toys for young
They are primarily designed as an aid for teachers of Design
Technology to encourage the practical development of young
should be carried out with the aid of a qualified adult. They are
Parts Size (mm)
1 50x50x50 Foot
2 250x1 LED Holder
1 ø5 Light source
1
1 2000 Light wire
1
Necessary tools:
Ruler and pencil
Drill 1mm and 5mm diameter
Piercing needle
Soldering iron and solder
Scissors
Acylic black or Edding black
Pliers
PLease Note
children
children. These projects
NOT suitable
for children und 3 years of age!
Description Part-N°:
1
2
3
Power source 4
5
Ball 6
1
