- Page 2 VAMPIRE NIGHT DX OPERATORS MANUAL T IS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY AT ALL TIMES AND IT IS IMPERATIVE THAT THE DETAILS SET OUT IN THIS MANUAL ARE FOLLOWED PRECISELY Issue 1 Part No. 90500127...
- Page 4 is a copyrighted anti-copying technology created by Sony Corp. This mark does not necessarily imply compatibility with other products bearing the “MAGICGATE” trademark. is a trademark of Sony Corporation. Le présent document vous informe que ce produit peut être soumis à la législation de contrôle des exportations nationales.
- Page 5 Contents ΕΞΕΤΑΣΗ ΓΕΝΙΚΗΣ ΑΣΦΑΛΕΙΑΣ ....................
-
Page 6: Table Of Contents
7. MAINTENANCE ........................59 7-1 Cleaning the Camera Window Covers ................61 7-2 Replacing the Fluorescent Tube or Starter ..............62 7-3 Replacing the Camera Assy ...................63 7-4 Replacing the Sensor ......................64 7-5 Removing th Switch Panel Assy ..................65 7-6 Replacing the Start Switches ...................66 7-7 Replacing the Gun Assemblies ..................67 7-7-1 Removing the Gun Covers ..................68 7-7-2 Separating the Gun Body ..................69... - Page 7 SAFETY NOTES...
- Page 8 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 9 SICHERHEITSHINWEISE...
- Page 10 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 12 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 14 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 15 MESURES DE SECURITE...
- Page 16 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 17 Καθώς αυτές οι πληροφορίες σε αυτ το εγχειρίδιο έχουν δοθεί µε καλή πίστη και ακριβώς την ώρα της τύπωσης , η εταιρεία NAMCO EUROPE LIMITED κρατάει το δικαίωµα να κάνει οποιεσδήποτε αλλαγές χωρίς ειδοποίηση. Τα µηχανήµατα έχουν κατασκευαστεί σύµφωνα µε τους ρους της Ευρωπαϊκής Κοιν τητας , και έχουν ελεγχθεί σύµφωνα µε τους ν µους...
- Page 18 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 20 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 22 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 24 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 25 AVISOS DE SEGURANÇA...
- Page 26 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 28 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 30 2m10cm or more 50cm or more 50cm or more PLAYZONE PATHWAY...
- Page 31 1. SPECIFICATIONS...
- Page 32 2. HOW TO PLAY • • • • • • • • • • • • •...
- Page 33 3. MAJOR COMPONENNTS Header Assy Projector Sensor Assy Gun Assy Playpanel Assy Gun cabinet Mains-In Assy...
- Page 34 4. MOVING THE MACHINE 5. INSTALLATION...
- Page 36 ΤΟ ΜΗΧΑΝΗΜΑ ΕΙΝΑΙ ΣΧΕ∆ΙΑΣΜΕΝΟ ΓΙΑ ΧΡΗΣΗ ΣΕ ΕΣΩΤΕΡΙΚΟ ΧΩΡΟ ΜΟΝΟ ΜΗΝ ΤΟΠΟΘΕΤΗΣΕΤΕ ΤΟ ΜΗΧΑΝΗΜΑ ΣΤΟΥΣ ΑΚΟΛΟΥΘΟΥΣ ΧΩΡΟΥΣ Εξωτερικά Απευθείας στον ήλιο,σε µέρη που υπάρχει υγρασία ή σκ νη,µέρη που υπάρχει άφθονο νερ ,κοντά σε air-condition ή άλλου είδους θέρµανση,µέρη µε υπερβολική υψηλή...
- Page 38 Removing the Header Assy The Header assy has a forward centre of gravity, so it is important that at least two (2) people are used to fit or remove the Header assy. The fitting position of the Header assy is high, and it is important that a means of reaching the height safely, without stretching, is available, (e.g.
- Page 39 Fitting the Gun Cabinet to the Monitor Cabinet Remove 4off hex head screws (M8x30) and remove the Joint Brackets from their shipping position. Refit the Joint Brackets as shown below with the 4off hex head screws (M8x30). Gun cabinet Joint bracket Hex head screws (M8x30) Place the Gun Cabinet close to the Monitor Cabinet and connect the connectors.
- Page 40 Approx. 5mm Castor Level adjuster Note: If the site of this game has a smooth or polished floor, it is recommended that rubber pads are fitted under the Level Adjusters to prevent the game sliding on the floor when in use.
- Page 41 • • • CD-ROM tray Operating lamp EJECT button Game PCB Assy CD-ROM Tray...
- Page 42 6 ADJUSTMENTS Μετατροπές ή επιδιορθώσεις στα µηχανήµατα πρέπει να γίνονται µ νο απ εξουσιοδοτηµένα άτοµα.
- Page 43 COIN COUNTER 2 Amp Q/B (Coin Fuse) PLAYER 1 SELECT DOWN ENTER TEST SERVICE...
- Page 44 The Test Switch must always be in the “OFF” position for normal game mode. MENU COIN OPTIONS Used to set the price of play GAME OPTIONS Used to set the game options I/O TEST Used for testing switches etc. MONITOR TEST Used to adjust the projector SOUND TEST Used to set sound levels Used to view bookkeeping...
- Page 45 Note:- The price of play on this machine is set within the Cashflow Coin Mech. Ensure that the Game Cost is set to 1 Coin 1 Credit. COIN OPTIONS [DEFAULT IN GREEN] GAME COST 1 COIN/S 1 CREDIT CONTINUE COST 1 COIN 1 CREDIT FREE PLAY EXIT...
- Page 46 GAME OPTIONS [DEFAULT IN GREEN] PLAYER'S LIFE MAX LIFE DIFFICULTY E(NORMAL-NORMAL) HIT COLOR HI-SCORE INIT EXIT SELECT SW:CHOOSE ENTER SW:ENTER...
- Page 47 I/O TEST GUN INITIALIZE SWITCH TEST EXIT SELECT SW:CHOOSE ENTER SW:ENTER...
- Page 48 GUN INITIALIZE ( a) OUT OF SCREEN 1P OUT OF SCREEN 2P (1P SIGHT MARK) This mark moves around the screen as the 1P gun is moved (2P SIGHT MARK) AIM AT SCREEN This mark moves around TO CHECK GUN ACCURACY the screen as the 2P gun is moved PUSH SERVICE SW :ADJUST GUN SIGHT...
- Page 49 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER...
- Page 50 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER...
- Page 51 1P GUN INITIALIZE AIM AT CENTRE OF THE CROSS AND PULL 1P GUN TRIGGER Aim the 1P gun at the cross in the bottom left of the screen and pull the trigger. The screen will revert to showing a cross in the centre of screen. Repeat the above procedures with the 2P gun.
- Page 52 I/O TEST SWITCH TEST COIN SERVICE TEST UP SELECT DOWN SELECT ENTER START 1P BUTTON START 2P BUTTON GUN 1P TRIGGER GUN 2P TRIGGER SENSOR UP SELECT SW+ENTER SW:EXIT • • Camera Assy CCD camera (inside) Interruption sensor (inside) •...
- Page 53 MONITOR TEST GRADATION PATTERN CROSSHATCH PATTERN (CRT) CROSSHATCH PATTERN (PROJECTOR) WHITE WINDOW (H) WHITE WINDOW (M) WHITE WINDOW (L) INTERLACE PATTERN VIEW ANGLE ADJUST (CRT) VIEW ANGLE ADJUST (PROJECTOR) FULL WHITE EXIT SELECT SW:CHOOSE ENTER SW:ENTER...
- Page 54 SOUND TEST [DEFAULT IN GREEN] VOLUME ALL SP [0〜64] 14 ATTRACT [0〜64] 14 REQUEST BGM VOICE MESSAGE: EXIT SELECT SW :CHOOSE ENTER SW :ENTER SERVICE SW :REQUEST ON/OFF...
- Page 55 ADS DATA GAME REPORT GAME HISTOGRAM ADS INITIALIZE EXIT SELECT SW :CHOOSE ENTER SW :ENTER...
- Page 56 GAME REPORT TOTAL COINS 00000000 TOTAL SERVICES 00000000 POWER ON TIME 000d00h00m00s TOTAL PLAY 00000000 000d00h00m00s FIRST PLAY 00000000 000d00h00m00s CONTINUE PLAY 00000000 000D00h00m00s FIRST CONTINUE 00000000 AVERAGE PLAY 00m00s LONGEST PLAY 00m00s SHORTEST PLAY 00m00s...
- Page 57 GAME HISTOGRAM 0M 00S 0M 29S 0000 0M 30S 0M 59S 0000 1M 00S 1M 29S 0000 1M 30S 1M 59S 0000 2M 00S 1M 29S 0000 2M 30S 2M 59S 0000 3M 00S 3M 29S 0000 3M 30S 3M 59S 0000 4M 00S 4M 29S...
- Page 58 ADS INITIALIZE ADS INITIALIZE EXIT SELECT SW :CHOOSE ENTER SW :ENTER...
- Page 59 OTHERS ROM1 Ver .00/12/09 SAT 02:27:14 CLOCK .00/12/22 FRI 16:05:54 123456-123456 BACKUP MEMORY INITIALIZE NO EXIT SELECT SW :CHOOSE ENTERSW :ENTER...
-
Page 60: Maintenance
7. MAINTENANCE Μετατροπές ή επιδιορθώσεις στα µηχανήµατα πρέπει να γίνονται µ νο απ εξουσιοδοτηµένα άτοµα. Να είναι σίγουρα κλειστ το ρεύµα πριν οποιαδήποτε δουλειά στο µηχάνηµα. -
Page 62: Cleaning The Camera Window Covers
Camera windows... -
Page 63: Replacing The Fluorescent Tube Or Starter
Security screw (M5x12) Retaining bracket Header Acrylic Header Vac-form Starter Fluorescent Tube Header Vac-Form... -
Page 64: Replacing The Camera Assy
Replacing the Camera Assy Remove 2off security screws (M5x12), disconnect the connectors and remove the Camera assy. Security screw (M5x12) Connectors Camera Assy Remove 2off Whizz nuts (M4) and remove the Camera Mounting bracket. Whizz nut (M4) Earth connector Camera mounting bracket Remove 2off pozi head screw (M2x30), Camera Filter (note which way round this filter is facing), 2off Spacers and the Camera PCB. -
Page 65: Replacing The Sensor
Replacing the Sensor Remove the Camera assy. (see 7-3 page 63) Remove 2off pozi head screws (M2.5x14), with flat and spring washers, and remove the Sensor. Camera unit Interruption sensor (note direction) × Pozi head screw (M2.5 (with flat and spring washers) Reassemble in reverse order. -
Page 66: Removing Th Switch Panel Assy
Removing the Switch Panel Assy Remove 6off button head screw (M6x12) and lift the Switch Panel Assy. Button head screw (M6x12) Switch panel Play panel Disconnect the connectors and remove the Switch Panel Assy. Earth Terminals Play Panel Connector Connectors Reassemble in reverse order. -
Page 67: Replacing The Start Switches
Play Panel Assy 1P Start Switch Assy Violet Black 2P Start Fast-On terminals Switch Assy Whi/Vio Black Fast-On terminals When replacing the switch, note which wires are on which terminals. -
Page 68: Replacing The Gun Assemblies
Replacing the Gun Assemblies Remove the Switch Panel Assy. (See 7-5 page 65) Disconnect the connector. Remove 2off Whizz nut (M4) and remove the Rope Hoop. Remove 2off Whizz nut (M6) and remove the Gun Assy. Gun Assy Connector cover Assy Rope hoop Gun bracket support plate Whizz nut (M6) -
Page 69: Removing The Gun Covers
Dome nut (M4) Socket cap screw (M3x10) Gun cover (L) Socket head screw (M4x25) Socket cap screw Gun cover (R) (M3x10) Note: Always reinitialize the guns if the guns has been removed or replaced. (see 6-2-3-1 page 47) -
Page 70: Separating The Gun Body
7-7-2 Separating the Gun Body Remove the Switch Panel Assy. (See 7-5 page 65) Remove the Gun Assembly. (See 7-7 page 67) Remove the Gun Covers (See 7-7-1 page 68) Remove 4off socket head screw (M4x10), 4off dome nut (M4). 1off socket head screw (M4x25), 1off socket cap screw (M3x10) and remove the Gun Body (R). -
Page 71: Replacing The Trigger Switch
Trigger switch (Yellow) N.O. terminal (Black) COM. terminal Note: Ensure that the correct wires are fitted to the correct switch terminals when refitting the Trigger Microswitch. Note: Always reinitialize the guns if the guns has been removed or replaced. (see 6-2-3-1 page 47) -
Page 72: Replacing The Gun Cable
Fast-On terminals Socket head screw Earth terminal (M4x10) Socket head screw PCB connector (M4x10) Connector cover Gun body (L) Gun cable Connector Note: When refitting the Gun Cable, ensure that the Earth terminal is refitted securely. Note: Always reinitialize the guns if the guns has been removed or replaced. (see 6-2-3-1 page 47) -
Page 73: Replacing The Rays Pcb
Replacing the RAYS PCB Remove 4off button head screws (M6x25) and remove the Maintenance Cover. Button head screws (M6x25) Flat washer Flat washer Maintenance cover Gun stand Assy Remove 2off button head screws (M5x10) and remove the Rays Cover. Button head screws (M5x10) RAYS cover Gun stand Assy Disconnect the connectors (x6) and remove the RAYS R PCB. -
Page 75: Parts
8. PARTS 12vDC SMPSU pBass Other side... - Page 76 c t i c t i...
-
Page 77: Service Bracket And Mains-In Assembly
c t i d i l c t i c t i t l i c t i c t i... -
Page 78: Gun Cabinet
l i h p i l... -
Page 80: Play Panel Assy
Play Panel Assy CAUTION c t i Page 79... - Page 82 d i l d i l d i l c t i i l e...
-
Page 83: Header Assembly
Header Assembly 10 11 (Opposite side c i l e l l c i l ½ " t t i Page 82... -
Page 84: Schematic
9. SCHEMATIC HEADER ASSY SP1 OUT - SP1 OUT + SP2 OUT - SP2 OUT + J104 D-sub BLUE AC NEUTRAL V RED GRN/YEL MOTHER FLUORESCENT ASSY GREEN EARTH V GREEN BROWN BLUE AC LIVE V BLUE PCB Assy BLACK J11 AMP MINI 2P AMP MINI 6P J12 V GND...
