Summary of Contents for NAMCO Ninja Assault SD
- Page 1 This document has been downloaded from: The largest resource for amusement machines documentation on the world wide web!
- Page 2 NINJA ASSAULT SD OPERATORS MANUAL T IS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY AT ALL TIMES AND IT IS IMPERATIVE THAT THE DETAILS SET OUT IN THIS MANUAL ARE FOLLOWED PRECISELY Part No. 90500119 Issue 1...
- Page 3 Page 2...
- Page 4 Contents ΕΞΕΤΑΣΗ ΓΕΝΙΚΗΣ ΑΣΦΑΛΕΙΑΣ ......................Page 3...
- Page 5 Page 4...
- Page 6 Do not make any alteration to this equipment without prior approval. Doing so could cause unforeseeable danger. Only parts specified by Namco Europe Ltd. should be used when replacing parts. (Including screws) Ensure that the power to the equipment is turned OFF before commencing any maintenance work.
- Page 7 Page 6...
- Page 8 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 7...
- Page 9 Page 8...
- Page 10 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 9...
- Page 11 Page 10...
- Page 12 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 11...
- Page 13 Page 12...
- Page 14 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 13...
- Page 15 Καθώς αυτές οι πληροφορίες σε αυτ το εγχειρίδιο έχουν δοθεί µε καλή πίστη και ακριβώς την ώρα της τύπωσης , η εταιρεία NAMCO EUROPE LIMITED κρατάει το δικαίωµα να κάνει οποιεσδήποτε αλλαγές χωρίς ειδοποίηση. Τα µηχανήµατα έχουν κατασκευαστεί σύµφωνα µε τους ρους της Ευρωπαϊκής Κοιν τητας , και έχουν ελεγχθεί σύµφωνα µε τους ν µους...
- Page 16 1m80cm or more 50cm or more 50cm or more ΣΗΜΕΙΩΣΕΙΣ ΓΙΑ ΤΗΝ ΕΓΚΑΤΑΣΤΑΣΗ ΠΟΤΕ να µην αν βει το µηχ νηµα ε ν δεν χει ολοκληρωθε η εγκατ σταση. Για την αποφυγ ηλεκτρικ ν σοκ πρ πει το µηχ νηµα να χει γειωθε . Για...
- Page 17 Page 16...
- Page 18 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 17...
- Page 19 Page 18...
- Page 20 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 19...
- Page 21 Page 20...
- Page 22 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 21...
- Page 23 Page 22...
- Page 24 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 23...
- Page 25 Page 24...
- Page 26 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 25...
- Page 27 Page 26...
- Page 28 1m80cm or more 50cm or more 50cm or more Play zone Pathway Page 27...
-
Page 29: Specifications
1. SPECIFICATIONS 230v /260watts AC +5°C to +25°C Hantarex 28” VGA Polo Mars CashFlow - 1 Channel Assembled 780(w) x 990(d) x 2190(h) Monitor Cabinet 780(w) x 890(d) x 1780(h) Header Assembly 740(w) x 210(d) x 430(h) Assembled 150kg Monitor Cabinet 145kg Header Assembly Keys:... -
Page 30: How To Play
2. HOW TO PLAY • • • • • • • • • • • • • •... -
Page 31: Major Components
3. MAJOR COMPONENTS Display panel (R) Display panel (F) Signboard Assy Start switch Control panel Assy Cabinet Assy Gun (R) Assy Gun (B) Assy Coin Assy Monitor NAOMI Mains-In Assy Power cord Control base Assy... -
Page 32: Moving The Machine
4. MOVING THE MACHINE 5. INSTALLATION... - Page 34 ΤΟ ΜΗΧΑΝΗΜΑ ΕΙΝΑΙ ΣΧΕ∆ΙΑΣΜΕΝΟ ΓΙΑ ΧΡΗΣΗ ΣΕ ΕΣΩΤΕΡΙΚΟ ΧΩΡΟ ΜΟΝΟ ΜΗΝ ΤΟΠΟΘΕΤΗΣΕΤΕ ΤΟ ΜΗΧΑΝΗΜΑ ΣΤΟΥΣ ΑΚΟΛΟΥΘΟΥΣ ΧΩΡΟΥΣ Εξωτερικά Απευθείας στον ήλιο,σε µέρη που υπάρχει υγρασία ή σκ νη,µέρη που υπάρχει άφθονο νερ ,κοντά σε air-condition ή άλλου είδους θέρµανση,µέρη µε υπερβολική υψηλή...
- Page 36 Top cover Security screw (M5x12) Security screw (M5x12) Pozi head screw (M6 x 16) Signboard Assy...
- Page 37 Front display Washer Header box Security screw (M5 x 12) Security screw (M5 x 12) Rear display...
- Page 38 Lock Nut Level Adjuster Castor Note: If the location site of this machine has a polished floor it is recommended that rubber pads are fitted under the level adjusters to prevent the machine sliding on the floor when in use.
- Page 39 6. ADJUSTMENTS Μετατροπές ή επιδιορθώσεις στα µηχανήµατα πρέπει να γίνονται µ νο απ εξουσιοδοτηµένα άτοµα.
- Page 40 COIN COUNTER 2 Amp Q/B (Coin Fuse) PLAYER 1 ENTER SELECT DOWN TEST SERVICE...
- Page 41 MENU COIN OPTIONS Used to set the price of play. GAME OPTIONS Used to set the game options. I/O TEST Used for testing switches and lamps. MONITOR TEST Used for adjusting the monitor. SOUND TEST Used to adjust the sound. ADS DATA Displays and resets bookkeeping data.
- Page 42 COIN OPTIONS [DEFAULT IN GREEN] GAME COST 1 COIN (S) 1 CREDIT CONTINUE COST 1 COIN (S) 1 CREDIT FREE PLAY EXIT SELECT SW : CHOOSE ENTER SW : ENTER Note:- The price of play on this machine is set within the Cashflow Coin Mech. Ensure that the Game Cost is set to 1 Coin 1 Credit.
- Page 43 GAME OPTIONS [DEFAULT IN GREEN] GAME DIFFICULTY C(MEDIUM) OFFICIAL RANKING MESSAGE ON HI-SCORE INITIALIZE EXIT SELECT SW : CHOOSE ENTER SW : ENTER e t I i r c c i f y t l i t i i l a i t i i l a...
- Page 44 GUN INITIALIZE SWITCH TEST LAMP & RECOIL TEST EXIT SELECT SW : CHOOSE ENTER SW : ENTER I/O TEST I/O PCB CHECK I/O PCB : Connect OK namco ltd.;JYU-PCB;Ver1.00;JPN, 1Coin 2Guns EXIT SELECT SW : CHOOSE ENTER SW : ENTER...
- Page 45 I/O TEST GUN INITIALIZE MENU GUN INITIALIZE (1P) GUN INITIALIZE (2P) EXIT SELECT SW : CHOOSE ENTER SW : ENTER GUN INITIALIZE (1P) SHOOT AT SCREEN TO CHECK GUN ACCURACY PUSH ENTER SW:ADJUST GUN SIGHT UP SELECT SW ENTER SW : EXIT...
- Page 46 GUN INITIALIZE (1P) AIM AT CENTER OF THE CROSS AND PULL GUN TRIGGER GUN INITIALIZE (1P) AIM AT CENTER OF THE CROSS AND PULL GUN TRIGGER Rear sight 10cm approx Line of Sight...
- Page 47 I/O TEST SWITCH TEST [ON:RED] COIN SERVICE TEST SELECT(UP/DOWN) OFF/OFF ENTER START BUTTON(1P) START BUTTON(2P) GUN TRIGGER(1P) GUN TRIGGER(2P) UP SELECT SW ENTER SW : EXIT...
- Page 48 I/O TEST LAMP & RECOIL TEST LAMP TEST START BUTTON(1P) LAMP ON START BUTTON(2P) LAMP ON RECOIL TEST PULL BOTH GUN'S TRIGGERS TO CONFIRM ACTION. EXIT SELECT SW : CHOOSE ENTER SW : ENTER...
- Page 49 MONITOR TEST GRADATION PATTERN CROSSHATCH PATTERN (CRT) CROSSHATCH PATTERN (PROJECTOR) WHITE WINDOW (H) WHITE WINDOW (M) WHITE WINDOW (L) INTERLACE PATTERN VIEW ANGLE ADJUST (CRT) VIEW ANGLE ADJUST (PROJECTOR) FULL WHITE EXIT SELECT SW : CHOOSE ENTER SW : ENTER...
- Page 50 SOUND TEST [DEFAULT IN GREEN] VOLUME ALL SP (0~127) ATTRACT (0~127) REQUEST SONG NO. MESSAGE ********** EXIT SELECT SW : CHOOSE ENTER SW : ENTER SERVICESW : REQUEST ON/OFF...
- Page 51 OTHERS [DEFAULT IN GREEN] ROM Ver. 00/09/20 WED 15:15:59 CLOCK --/--/-- --:--:-- 000000- 123456 LANGUAGE PAUSE NAOMI TEST MODE BACKUP MEMORY INITIALIZE EXIT SELECT SW : CHOOSE ENTER SW : ENTER...
-
Page 53: Maintenance
7. MAINTENANCE Μετατροπές ή επιδιορθώσεις στα µηχανήµατα πρέπει να γίνονται µ νο απ εξουσιοδοτηµένα άτοµα. Να είναι σίγουρα κλειστ το ρεύµα πριν οποιαδήποτε δουλειά στο µηχάνηµα. - Page 55 Front display Washer Header box Security screw (M5 x 12) Header box Security screw (M5x12) Security screw (M5x12) Font panel...
- Page 56 Security screw (M5 x 20) Play Panel Assy Security screw (M5 x 20) Play panel Connector...
- Page 57 Note: Ensure that the wires are replaced to the correct terminal. Play panel (rear) Lamp Start switch Fast-On terminal...
- Page 58 Note: Take care not to lose the shakeprrof washer under the Earth Terminals. Note: Ensure that the shakeproof washer is refitted under the Earth Terminals. Gun Assy Connector cover Play panel Whizz nut (M6) Shakeproof washer Earth terminal Whizz nut (M6) Connector Play panel (rear)
- Page 59 Hexagon cap nut (M4) Cap bolt (M3 x 10) Gun slide (L) Button bolt (M4 x 25) Cap bolt (M3 x 10) Gun slide (R)
- Page 60 Hexagon cap nuts (M4) Button screw (M4 x 25) Gun casing (L) Lens Button screw (M4 x 10) Gun casing (R) Button screws (M4 x 10) Cap screw (M3 x 10) Ensure that the flat face of the lens is facing the back of the gun).
- Page 61 Solenoid Cap bolt (M3 x 10) Solenoid bracket Connector Earth Shakeproof washer terminal Cap screw (M) (M3 x 8) Cap screws (M) (M4 x 6) Nut (nominal dia.16) Slide guide Solenoid Plunger...
- Page 62 Note: When reassembling match the D-type hole of the solenoid bracket to the D shape of the solenoid and ensure that the ‘E’ ring and spacers are in the correct positions. Solenoid Spacers Slide guide Solenoid bracket Plunger E-ring Harness exit (downwards) Microswitch Blue wire.
- Page 63 Fast-On terminals (microswitch) Earth terminal Connector (solenoid) Button screw (M4 x 10) Connector (sensor) Button screw Connector cover (M4 x 10) Gun casing (L) Earth terminal Connector Tube...
- Page 64 Security screw (M5 x 20) Speaker grille Monitor glass Security screw (M5 x 20) Play Panel Assy Security screw (M5 x 20)
- Page 65 Monitor glass...
- Page 66 Mirror Locating notch Retaining bracket Pozi head screw (M5 x 16)
- Page 67 Pozi head screw (with flat/spring washer) (M6 x 16) Monitor mask Connector (x2) Monitor...
- Page 68 Pozi head screws (with flat/spring washer) (M8 x 20) Washer Monitor adapter Monitor adapter Monitor...
- Page 69 8. PARTS (Opposite side) 31 32 Front (Opposite side...
- Page 70 e l l r r i r r i r r i e l l ½ " " 8...
- Page 71 v i t v i t v i t v i t c i t...
- Page 72 u l l...
- Page 74 d i l d i l d i l d i l d i l l i a p i l d i l d i l d i l d i l d i l c t i e l i i l e...
- Page 75 c t i c t i...
- Page 76 i f i t...
- Page 77 GUN ASSY (1P) 9. SCHEMATIC SOL_RET J36 MINI J37 MINI SOLENOID ASSY S_OUT J38 EI TRIGGER SENSOR PCB ASSY PLAYER 1 START GUN ASSY (2P) SOL_RET J39 MINI J40 MINI HEADER SOLENOID ASSY FLUORESCENT ASSY PLAYER 2 START S_OUT J41 EI TRIGGER SENSOR PCB ASSY SERVICE BRKT...
- Page 78 Copies of Namco Game Manuals can be downloaded from our website: www.namco.co.uk under Components Distribution For all Parts or Technical Support contact: Brent Spares, Namco House, Units 5-8, Acton Park Estate, The Vale, London. W3 7QE www.namco.co.uk For Technical Support, Warranty and...
