ATN PVS7-CGT Specifications

AMERICAN TECHNOLOGIES
NETWORK, CORP.
atn pvs7-CGT
atn pvs7-CGT
ATN PVS7-CGT available with a quality
made CGT generation image intensifier
tube. The ATN PVS7-CGT is full robust,
dependable, high performance night vision
goggle. This model is identical to AN/PVS7
model adopted as a standard issue to US
Army ground troops, designed to assist
viewing and provide reliable service in the
most unfavorable conditions. Full U.S. Mil
Spec body with goggle assembly, soft
carrying case, demist shield, sacrificial filter
for objective lenses,
head-mount assembly with 3 brow pads,
lens tissue, neck cord and front lens cap.
OPTICAL
Field of View: 40°
Min. Focus Range: 20 cm
Objective:
Focal Length: 26 mm
F-Number: 1.17
T-Number: 1.3
Eyepiece:
Diopter Adjustment: +2 to -6
Eye Relief: 15 mm
Interpupillary Adjustment 55 mm to 71 mm
MECHANICAL
(Standard goggle without Afocal)
Weight:(Goggle w/Mask Assy): 650 grams/ 1.4 lbs
Dimensions: 140.8 mm long x 155.6 mm wide/
5.54" x 6.12 lbs
ELECTRICAL
Power Source: 2 - AA Batteries (Alkaline) or
1 - BA-5567/U (Lithium)
Battery life: 50 hours
ENVIRONMENTAL
Operating Temperature: - 40 °C to + 50 °C
Storage Temperature: - 50 °C to + 70 °C
Humidity: 90% up to +65 °C for 240 hours
Immersion: 1 meter for 30 minutes
Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control
jurisdiction of either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
American Technologies Network Corp.
1341 San Mateo Avenue, South San Francisco, CA 94080
800-910-2862, 650-989-5100, FAX 650-875-0129
shoulder strap,
• Adjustable head mount
• IR illuminator
• Momentary IR-on switch
• Automatic high-light cutoff
• Flexible carrying case
• Operates on one lithium
or two AA alkaline batteries
• Two-year warranty
HIGH QUALITY CGT GEN IMAGE INTENSIFIER TUBE
DESCRIPTION.................................
GENERATION..................................
PHOTOCATHODE TYPE...................
RESOLUTION*..............................
SIGNAL-TO-NOISE RATIO*.............
EXPORT...........................................
FIGURE OF MERIT ..........................
* Specifications are provided for informational purposes only. Actual values may vary
www.atncorp.com
E-mail: info@atncorp.com, sales@atncorp.com
CUSTOM
CGT
MULTI - ALKALI
45 - 54 lp/mm
16 - 22
N/A FOR EXPORT
LESS THEN 1250
