Summary of Contents for Atlantic Technology 372 PBM THX
- Page 1 Model 372 PBM THX ® High Performance THX Powered Subwoofer System Atlantic Technology ® N N O V A T I V E O M E H E A T E R 343 Vanderbilt Avenue Norwood, MA 02062 (781) 762-6300...
- Page 2 Atlantic Technology Model 372 PBM THX ® High Performance THX Powered Subwoofer System Star Wars...
- Page 3 Atlantic Technology Model 372 PBM THX ® To prevent risk of electrical shock or damage to your equipment, always unplug all component AC cords before proceeding with speaker and component connections! The last step in wiring your system is plugging in the AC cords!
- Page 4 Atlantic Technology Model 372 PBM THX ® Figure 1: Amplifier panel and controls for Model 372 PBM THX...
- Page 5 Model 372 PBM THX Example 1: Subwoofer Line Out/ Low Level In This is the most commonly used system connection for systems with surround sound receivers/ processors. Example 2: Preamp Line Out/Low Level In for Option 1 1 Subwoofer This arrangement...
- Page 6 Model 372 PBM THX Example 3: Preamp Line Out/Low Level In for Y-adapters 2 Subwoofers Note that the L/MONO input is used on both sub- woofers. Instead of Y-adapters, you may also use the THRU outputs to connect back to...
- Page 7 Model 372 PBM THX Example 5: Speaker Out/ High Level In for 1 Subwoofer This is the most common method for connecting a subwoofer to a system without a dedicated sub- woofer line out or Preamp outputs. Left Front Speaker...
-
Page 8: Power Connection
Model 372 PBM THX THX Example: THX Subwoofer Option 1 Out/Low Level In THX Receiver/Amplifier/Processor Option 1 is the most commonly used method of Woofer connecting two subwoofers to a THX system. You may also use a Y- adapter as shown... -
Page 9: Changing The Fuse
Atlantic Technology Model 372 PBM THX ® Figure 3: Changing the Fuse The fuse is located next to the IEC AC socket Insert screwdriver tip here Placement and Operation Figure 4: Typical arrange- ment for a single subwoofer in a home theater. - Page 10 Model 372 PBM THX Subwoofer Tuning—Using the Variable Level Control Figure 5: Front Panel Variable Level Control located behind the removable grille the subwoofer too loudly. Figure 6: Assymmetrical arrangement for 2 subwoofers in a home theater, for example, one...
-
Page 11: The Phase Invert Mode
Model 372 PBM THX THX Settings The Phase Invert Mode A Word About Center Channel Modes Subwoofer Troubleshooting Guide Problem Possible Cause No bass output AC power cord unplugged or plugged into a non-working outlet. Input cables not securely connected or defective. -
Page 12: For Future Reference
Power Requirements Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifications or designs at any time without notice. THX and Lucasfilm are registered trademarks of Lucasfilm Ltd. Dolby Digital, AC-3, Dolby Stereo and Dolby Pro Logic are trademarks of Dolby Laboratories Licensing Corporation.
