Summary of Contents for Atlantic Technology T70.1PBM
- Page 1 Model T70.1 PBM High Performance Powered Subwoofer Atlantic Technology ® N N O V A T I V E O M E H E A T E R 343 Vanderbilt Avenue Norwood, MA 02062 (781) 762-6300 www.atlantictechnology.com...
- Page 2 Sealed enclosure designs are inherently low in distortion and naturally deliver deep, smooth bass response with a gradual and predictable roll-off below resonance. As with all Atlantic Technology subwoofers, we have paid inordinate attention to giving you accurate musical bass reproduction along with terrific special effects.
- Page 3 The outputs allow daisy chaining of multiple subwoofers, or can act as a return path back to the processor. Two high level inputs, two high level outputs These let you connect the subwoofer to your amplifier using the amplifier’s speaker outputs. The speaker outputs may be connected to the left and right front satellite speakers. Figure 1:...
-
Page 4: Connecting Your Subwoofer
Designed and built to meet all CSA and CE safety requirements Connecting Your Subwoofer The Atlantic Technology System T70.1 PBM Powered Subwoofer is simple to hook up, offering several connection methods for maximum flexibility. Study the system diagrams starting on the next page. - Page 5 3. Option 3 Single Subwoofer Receiver/Amplifier/Processor LEFT RIGHT MAIN IN PRE OUT LEFT RIGHT MAIN IN PRE OUT PRE AMP LEFT RIGHT MAIN IN INTERNAL EXTERNAL PRE OUT Atlantic Technology ® Optional Second Subwoofer Single Subwoofer...
- Page 6 Main Inputs as shown in Option 2 of Example 2. Example 4: Speaker Out/ Right Speaker High Level In for 1 Subwoofer This is the most common method for connecting a...
-
Page 7: Power Connection
It is important to observe polarity while making speaker connections: red (+) terminals on the ampli- fier to red (+) on the speaker, black (–) on the amplifier to black (–) on the speaker. Look carefully at the wires you are using and note that one of the wires in each pair will be marked by either the con- ductor color, printing on the wire jacket, a ridge on one side of the wire jacket, or a thread intertwined with the wire strands. -
Page 8: Placement And Operation
Model T70.1 PBM with no signal detected from the rest of the system, the amplifier will shut itself off and go into standby mode. Power consumption in the standby mode is negligible. Standby operation can be completely bypassed by placing the “Auto” switch in the “On” position. In this mode, the subwoofer will be controlled by the position of the Main Power switch. - Page 9 “picture.” The low frequency response of the T70.1 satellites has been optimized to work with approximately a 100Hz crossover point. This provides maximum performance and the smoothest integration with the subwoofer. Atlantic Technology ®...
-
Page 10: Care And Feeding Of Your Subwoofer
Management option, which lets you set the front and rear speakers in a limited bandwidth (Small) or full range (Large) mode. All Atlantic Technology speakers are designed to be used in the Small setting with such a controller. However, when using high level connections, the Large setting should be used. -
Page 11: Subwoofer Troubleshooting Guide
Model T70.1 PBM Specifications Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifications or designs at any time without notice. Dolby Digital, AC-3, Dolby Stereo and Dolby Pro Logic are trademarks of Dolby Laboratories Licensing Corporation. DTS is a registered trademark of DTS Technology. -
Page 12: For Future Reference
Record your speaker serial number and date of purchase here: Model Number The serial number is found on the back of the speaker near the connecting terminals. The lightning flash with arrowhead, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous...
