- Page 1 Model 102 SB Model 212 SB Model 422 SB High Performance Powered Subwoofers 422 SB 212 SB 102 SB...
-
Page 2: Table Of Contents
The serial number is found on the back panel. Copyright © 2004 Atlantic Technology International. Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifications or designs at any time without notice. THX and THX Ultra 2 are registered trademarks of Lucasfilm, Ltd. -
Page 3: And 212 Sb Subwoofer Rear Panel
An adjustable (40Hz to 140Hz) @ 18dB per octave low-pass cross- over.(pages 5 and 9) Phase Switch This switch allows precise acoustic matching with satellite speaker systems whose output may be phase reversed.(pages 5 and 10) Crossover Switch When in the NORMAL position, adjustment of the crossover can be made by the Crossover Control.If being fed a pre-filtered or THX... -
Page 4: Sb Subwoofer Rear Panel
An adjustable (40Hz to 140Hz) @ 18dB per octave low-pass cross- over.(pages 5 and 9) Phase Switch This switch allows precise acoustic matching with satellite speaker systems whose output may be phase reversed.(pages 5 and 10) Crossover Switch When in the NORMAL position, adjustment of the crossover can be made by the LowPass Control.If being fed a pre-filtered or THX... -
Page 5: Features
■ Many subwoofers offer specifications that look great on paper,but in real world use deliver less than promised. Atlantic Technology sub- woofers are over-designed to ensure that they will deliver their rated performance in your room,when properly placed and adjusted. -
Page 6: Subwoofer Line Out To Low Level In
WARNING: To prevent risk of electrical shock or damage to your equipment, always unplug all component AC cords before pro- ceeding with speaker and component connections! The last step in wiring your system should be plugging in the AC cords! Subwoofer Line Out to Low Level In Run an RCA cable from your receiver’s Sub Out jack to the L/Mono input... -
Page 7: Low Level Connections With One Subout/Lfe Output
Instruction Manual Low Level Connections with One Subout/LFE Output Figure 3 Sub Out/LFE L/MONO OUTPUT INPUT Low Level Connections... -
Page 8: Low Level Connections With Two Subout/Lfe Outputs
Low Level Connections Low Level Connections with Two Subout/LFE Outputs Figure 4 Sub Out/LFE Sub Out/LFE L/MONO OUTPUT INPUT Model 102, 212 and 422 SB Powered Subwoofer... -
Page 9: Subwoofer Tuning Without An Spl Meter Or Test Tones
SPL meter to the 70dB scale, Slow Response, and C Weighting. Now, holding the meter pointed up and in front of you,let the system cycle its test tone from speaker to speaker and set every speaker to 75dB using the individual level settings in the Processor/Receiver.As tempting as it may be to set the subwoofer and/or surround speakers higher than 75dB, listen again after calibration and see if you can acclimate to these levels. -
Page 10: Using The Subwoofer Crossover Control
Care of Your Subwoofer The 102 SB, 212 SB and 422 SB are constructed from Medium Density Fiberboard. MDF is a non-resonant material ideal for speaker system enclosures. To clean the cabinet you may use a soft cloth either dry or slightly dampened with clean water.Be careful not to wet the cabinet or... -
Page 11: Subwoofer Troubleshooting Guide
50/60Hz, 300W Max Specifications are those in effect at the time of printing.Atlantic Technology reserves the right to change specifications or designs at any time with- out notice.THX is a registered trademark of Lucasfilm Ltd.Dolby Digital, Dolby Stereo, and Dolby Pro Logic are trademarks of Dolby Laboratories Licensing Corporation.DTS is a registered trademark of Digital Theater Systems,Inc. - Page 12 343 Vanderbilt Avenue Norwood,MA 02062 (781) 762-6300 www.atlantictechnology.com 015-0442-A...
