Handle set
Table of Contents

Advertisement

5
7
Griffeinleger entsprechend Einleger-dicke wählen/

Select the insert according to the inlay thickness.

9 WC
6
8
5 Nm
3 mm
Bei neuer Montage neue Madenschraube
verwenden

please use new grub screw for new mounting.

10 WC
2,5 mm
3 Nm

Demontage Einleger

Montage Einleger

5 Nm
Griffeinleger für 0,8mm starke Einleger

Insert for Inlays with 0,8mm thickness

1
Griffeinleger für 3,0mm starke Einleger

Insert for Inlays with 3,0mm thickness

2
Technische Änderungen vorbehalten / subject to alterations 05/2019 cq
