IMPORTANT INSTALLATION INSTRUCTIONS FOR SMART2LOCK

BEFORE INSTALLATION

1. Check the frame: The frame must not bulge in the vicinity of the striking plate.
This can be checked using a long spirit level or straightedge.
2. Checking the lockable grip: Check whether the lock opens and closes before installation.
ATTENTION! The square spindle must not be inserted into the handle for this.
3. Check the latch projection at the lock: 10 mm as standard, unchecked locks
often only have 8 mm.
10 mm
Only valid for ONE door handles:
Adjust substructure so that it is parallel with the handle, if it is incorrectly adjusted.
INSTALLATION VIDEOS
Step by step guide in suitable installation video:
ONE door handles
>> VIDEO
GRIFFWERK GMBH | LINDENSTR. 90 | 89134 BLAUSTEIN | PHONE +49 731 93 80 89-20 | FAX +49 731 93 80 89-29 | INFO@GRIFFWERK.DE
-
+
Piatta S
>> VIDEO
+
-
Clip-on system
>> VIDEO
Screw-on system
>> VIDEO
