Contents Information regarding the pres- sure vessel ....18 Pressure tank ....18 Important information Instructions for use for the pres- About this document .
Page 4
Contents Contact 14 Addresses ..... . 32 14.1 Returns / Repairs ... . . 32 14.2 To order spare parts .
Important information About this document The signal word differentiates between four levels of danger: These installation and operating instructions – DANGER represent a part of the unit. They correspond to Immediate danger of severe injury or death the relevant version of the unit and the status of –...
Important information Safety AC current Dürr Technik has developed and constructed Green control LED "Unit ready for opera- the units in such a way that danger is to a large tion" extent excluded if the units are used as intend- ed.
The SICOLAB med unit does not have any es- patient. sential performance characteristics in accord- The ventilator must have a suitable ance with EN/IEC 60601-1 section 4.3.
Important information Ambient conditions during storage and WARNING transport Risk of explosion of the pressure vessel and pressure hoses Ambient conditions during storage and The unit is pressurised and may explode transport if you do not comply with the notice. temperature °C -20 to +70...
Product description Technical data 4.1 Basic data Electrical data Basic unit Nominal pressure bar / MPa 3 / 0.3 General data Pressure vessel volume Delivery quantity at 3 bar (0.3 MPa) l/min Duty cycle Operating pressure, max. bars Max. 5 2.7 ±...
Product description 4.2 Variants Nominal voltage Electrical fre- Nominal current Output Fuses quency P1 (kW) IEC 127-2/V Units without transformer 220-240 T4H250V Units with transformer 220-230 T4H250V 115-120 50 or 60 T8H250V 50 or 60 T8H250V 50 or 60 T8H250V 50 or 60 T8H250V 1018100100L02 1907V005...
Manufacturer's address: D-74321 Bietigheim-Bissingen Reference number: 1018 Article designation: SICOLAB med From the serial number: H400000 We hereby declare that the product described above conforms to the requirements of the valid ver- sion of the Medical Devices Directive 93/42/EEC. The device fulfills the requirements of the following pertinent directives:...
Product description Operation If the unit is to be used as the main source of air supply for a ventilator, the pressure hose (not included in the scope of delivery) must be connected to the compressed air supply (10) of the unit and must be connected to the ventila- tor.
Product description 5.2 Pneumatics plan Filter mat (aspiration) 10 Compressed air connection for the ventilator 11 Connector for central compressed air supply in standby mode 20 Air intake filter 21 Regulating valve 22 Compressor unit 23 Cooler 24 Sub-micro filter 0.3 µm 25 Condensate separator 26 Membrane dryer 26a Fine filter 5 µm...
Product description 5.3 Main air supply Ambient air is aspirated via the air intake filter on the regulating valve, compacted in the compressor and cooled in the cooler. The compacted air is cleaned in the pre-filter, the condensate is separated in the condensate separa- tor and discharged.
Product description Type plate The type plate is located on the rear of the unit. 1018101001 DSKJ-0000 0297 1018101001DSKJ-0000 IP: 20 V ~220-230 Hz 60 nom. 40 Kg (88 lbs) A 2,4 T4H250V 2017-08-23 5x20mm IEC 127-2/V Date of manufacture Duerr Technik GmbH&Co.KG Pleidelsheimer Str.
Assembly Tools required Requirements – Torque wrench 8.1 Installation/setup room – Hexagon keySW12 The room chosen for set up must fulfil the fol- – Allen wrench SW 3 lowing requirements: – Closed, dry, well-ventilated room. – Should not be a purpose-made room (e. g. boiler room or wet room).
Assembly 8.2 Information regarding the pressure vessel The owner must comply with the national directives. The container of the unit is smaller than 250 bar L. Therefore, EU countries do not require a periodic safety inspection. Those operating the device outside the EU must check the valid national directives pertaining to the container inspection and implement them if necessary.
Assembly 8.4 Instructions for use for the pressure vessel (explanation by Be- hälter-Werk Burgau GmbH) The pressure vessel must only be used in accordance with the aforementioned intended purpose and in accordance with the specified technical data. Other forms of use are not permitted for reasons of safety.
Assembly Commissioning Install the castors without wheel lock in the rear boreholes on the underside of the unit. 9.1 Remove the packaging The unit is securely protected with packaging material to ensure safe transportation. Remove the packaging material. Check the unit for damage in transit. Lift the unit off the floor.
Assembly 11 Connector for central compressed air sup- NOTICE ply in standby mode The use of a non-approved power cord can have a negative effect on There are two compressed air connectors on the electrical safety and EMC. the rear of the unit. The upper compressed air connection (10) is connected to the ventilator The use of non-approved accessories, via a pressure hose.
Assembly Guide the power cord through the strain relief NOTICE without any mechanical stress and screw Automatic start-up of the unit after down the strain relief. cooling down Allow unit to cool down The motors in the units are equipped with a temperature switch that switches the unit off if it overheats.
Usage 10 Operation The green indicator lamp (10) is off = OFF. 10.1 On/Off switch Move the on/off switch (5) on the rear of the unit to the "I" position to activate the unit. The units starts up and the pressure vessel is filled.
Usage 11 Maintenance De-energise the unit prior to working on it or in the event of potential danger (e. g. pull the mains plug) and prevent it from being switched back on again. Perform an inspection and maintenance no later than after one year or 5000 operating hours. If needed, service the unit at shorter intervals.
Usage 11.2 Disinfecting and cleaning the surfaces The surface of the unit can be disinfected with disinfectant wipes. Preparations from the group of surface disinfectants should be used for this purpose. For reasons of materials compatibility, preparations based on the following agents are suitable: - Aldehydes - quaternary ammonium compounds.
Troubleshooting 12 Tips for operators and service technicians Perform an inspection and maintenance no later than after one year or 5000 operating hours. If needed, service the unit at shorter intervals. Maintenance and repair work may be done only by Dürr Technik or Dürr Technik-qualified per- sonnel/service engineers.
Page 29
Troubleshooting Fault Probable cause Solution The orange warning LED ambient temperature too high Disconnect the unit from the "Temperature too high" mains supply and allow it to cool is on and a permanent down. acoustic signal is issued Provide for unobstructed air circulation.
Appendix 13 Information about EMC in accordance with EN 60601-1-2 13.1 General notes The information in this leaflet includes excerpts from the relevant European standards for electrical, medical devices. Comply with the information provided in this leaflet when you install and combine in- dividual Dürr Technik units with products from other manufacturers.
Page 31
Appendix Interference immu- IEC 60601 - test Compliance level Electromagnetic environment nity tests level - guidelines Voltage drops, 0 % U (100 % drop 0 % U (100 % drop The quality of the supply voltage short-term interrup- in the U ) for 1/2 pe- in the U ) for 1/2 pe-...
Page 32
Appendix Electromagnetic interference immunity for devices or systems that are not life-sustaining Portable and mobile communication devices should not be used any closer to the unit (including ca- bles) than the recommended safety distance, which is calculated based on the applicable formula for the transmission frequency.
Page 33
Appendix Recommended safety distance between portable and mobile HF communication devices and the unit The device is designed for use in the electromagnetic environments specified below, in which the HF disturbance variables are controlled. The customer or the operator of the device can help to prevent electromagnetic interference by maintaining the minimum distances between mobile HF communica- tion equipment (transmitters) and the device as recommended below in accordance with the maxi- mum output line of the communication equipment.
Page 34
Contact 14 Addresses 14.1 Returns / Repairs Dürr Technik GmbH & Co. KG Pleidelsheimer Straße 30 74321 Bietigheim-Bissingen -Germany- WARNING Risk of explosion of the pressure tank and pressure hoses The pressure tank and the pressure hoses must be vented before they are stored or trans- ported.
