Storch ProCut multi Manual page 48

Fig. 3: Front view, operating position (cutting bow and bearing rail
unfolded)
9 = On/Off switch on the transformer
10 = Base plate
11/a/b = Board support
12 = Retractable slider for repeat cuts
14 = Scale for rebate and section cut-outs
15 = Depth limiter for section cut-outs
16 = Fold-out mitre aid
17 = Scale for angle cuts
Fig. 4: Using the device on the freestanding support (no. 18, art. no. 57 00 50)
18 = Freestanding support
15
16
17
11b
14
15
48
10
11a
9
12
18
11
8
