Assembly Book
Revised on April 19, 2018
Northwood Deluxe
10'x10'
Manufactured by Reynolds Building Systems, Inc.
205 Arlington Drive
Greenville PA, 16125
This manual is copyrighted. Under the copyright laws, this manual
may not be copied, in whole or in part, without consent from Reynolds
Building Systems, Inc.
© Copyright 2011

Advertisement

loading
Need help?

Need help?

Do you have a question about the Northwood Deluxe 10x10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Best Barns Northwood Deluxe 10x10

Summary of Contents for Best Barns Northwood Deluxe 10x10

  • Page 1 Assembly Book Revised on April 19, 2018 Northwood Deluxe 10'x10' Manufactured by Reynolds Building Systems, Inc. 205 Arlington Drive Greenville PA, 16125 This manual is copyrighted. Under the copyright laws, this manual may not be copied, in whole or in part, without consent from Reynolds Building Systems, Inc.

  • Page 2: Tool List

    MPORTANT NFORMATION BOUT Thank you for purchasing our shed kit. These instructions will construct a 10'x10' building. If you received two books, use the one with the latest revision date. Read the instructions before starting the assembly of the building. If you have any questions about assembling the kit, call 800-245-1577.
  • Page 3 Material Purchased Locally 10'x10' Building 6 bdl. Roof Shingles pcs. Roof 'drip' edge 14'x10' Building 8 bdl. Roof Shingles pcs. Roof 'drip' edge General Construction Guidelines Siding is made in sheets with grooves cut into the LAP Edge face, the long edge is beveled so that the siding overlays where they butt.
  • Page 4 Constructing Details for Deluxe Floor System Deluxe floors include 4x4 runners, standard floors do not Check local building codes in your area, the construction may have to change. For a concrete slab, install sill sealer as a moisture barrier between the concrete and the wall plates. Foam sill sealer can be purchased at home centers in rolls 3-1/2"...
  • Page 5 Step 1 Assemble Trusses Building Tip: To aid in the assembly of the trusses, temporarily tack 2x4 blocks to the floor. There are short 2x4s, that may have an angle on one end, supplied in the kit for this purpose. This will trap the truss parts and insure that all the trusses will be assembled the same.
  • Page 6 Step 2 Assemble Roof Gables 1. Use the remaining truss parts to assemble the roof gables. Position 2x4s between the blocks. 2. Place (2) two 20-3/4" long gable studs between the top and bottom 2x4s. The siding will secure them in place. 20-3/4"...
  • Page 7 Step 3 Assemble Back Wall 1. Locate (2) two 2x4 boards 68-1/2" long [green ends] and (2) two boards 41-1/2" in length. Position these boards together and indicate with 'X' marks, where the wall studs will be located. 68-1/2" Wall Plate 41-1/2"...
  • Page 8 Step 4 Assemble Left Sidewall 1. Locate (2) two 2x4 boards 69" long and (2) two boards 51" in length. Position these boards together and indicate with 'X' marks where the wall studs will be located. 69" Wall Plate 51" Wall Plate 20-1/4"...
  • Page 9 Step 4 Assemble Left Sidewall Continued 4. Square wall frame. Install a 45-3/4" siding panel, with cut edge, at the end of the wall and extending 3/4" below the bottom plate. Install a full width siding panel. 27" Siding 6. Install a 27" wide siding panel last. Panel Tongue Edge Cut Edge...
  • Page 10 Step 6 Assemble Door Walls 1. Gather (5) five 72" wall studs, (2) two 31-3/4" and (2) two 10-3/4" long 2x4 wall plates [coded A]. Assemble these 2x4s using 10d sinkers. 2. Install 71-1/2" long 2x4s [red ends], as header supports, on each wall frame. 10-3/4"...
  • Page 11 Step 7 Assemble Door Wall If you want the door opening on the left, flip the walls and apply siding to the opposite side of the wall frames. Tongue Edge 1. Select the larger wall frame. 21-1/2" Wide Siding Panel LAP Edge Cut Edge Siding Extends...
  • Page 12 Step 8 Set Lower Walls 1. Secure wall panels together at the corners. Use (4) four 10d coated nails per corner. Nail wall panels to the floor. Nail through the bottom plate. Space 10d sinkers 24" apart. 2. Install the 2x4 door header between the front wall panels. The siding extends 1-1/2" above the top of the door header to receive 2x4 tie plate.

  • Page 13: Step 9 Install Trim

    Step 9 Install Trim Use 8d galv. nails when installing trim. 1. Install lx3x72" trim boards along each side of the door opening. Tack these boards with a couple nails; you may want to move the trim later when you install the doors. 2.
  • Page 14 Step 10 Install Gable on Right Sidewall 1. Install the gable on the right sidewall. The gable siding will extend over the 1x4 trim on the lower wall. Secure gable to wall by Right Gable nailing through the gable blocks with 10d sinkers.
  • Page 15 Step 11 Install Trusses Continued 3. Place a truss in the front hanger and over the 'X' mark on the back wall. Important; the 2x4, not the wood gusset, should cover the 'X' mark on the rear 2x4 plate. Check the truss spacing, front and back, to make sure the truss is parallel.
  • Page 16 Step 13 Install Front Soffit 1. Secure the front of the trusses to the H1 hangers with 1-1/2" hanger nails. 2. Install 21" soffit panels under the front overhang. Cut the first soffit panel to meet the center of the truss. Fasten to the trusses with 6d galv. nails. 3.
  • Page 17 Step 15 Install Roof Sheathing 1. Cut a 73-1/2" long 1x6 fascia board to fit flush with the trim on the gable and meeting the center of the truss. Install the fascia so the bottom edge of the roof sheathing will rest on the edge.
  • Page 18 Step 16 Install Loft flooring 1. Gather (2) two 24" x 48" and (2) two 16-1/2" x 48" pieces of OSB sheathing. Install these panels over the bottom 2x4 truss member. Secure with 7d sinkers. 2. Notch panels around gable studs. 3.
  • Page 19 Step 17 Install Doors & Hardware 1. Lay the left door with the trim facing up. The siding on the left door extends past the door trim. See detail below. 2. Install 5" hinges to the left side of the door frame. To position the hinge properly, hold the rectangular plate against the frame.
  • Page 20 Northwood 10' x 10' Barn kit Packing List 20-May-14 Qty. Qty. Description Size Description Size 2x4 Framing 1x6 Whie Pine Fascia Truss Material - bottom cords " Fascia 1/2" 12 Truss Material-top members 79 5/8" Fascia " 28 Wall Studs/Plates - black ends "...
