Specifications
TBS Fusion module
Input Power:
5-9v (2s LiPo)
Extras:
WiFI for TBS Cloud connectivity
OSD
Real-time picture processing
Features
Matrix Modus, Auto search, Race mode
CRSF menu, Find mode, Laptimer, OSD
Channels:
Band A/ B/ E
Fatshark
Race Band
Low Race Band
Audio:
Passthrough to your goggles
Power consumption:
WiFi off: 5V: 380 mA, 8.4V: 270 mA
WiFi on: 5V: 440 mA, 8.4V: 320 mA
Antenna connectors:
Micro USB, 2x SMA antenna connector
Connector:
Pins: 2,5mm pin header, 9 Pins
Weight:
30,5g
WiFi:
IEEE 802.11 b/g/n (2.4 GHz)
OLED:
64x128 Oled (blue)
Kit contents:
1x TBS FUSION, 1x power mod board, 2x ribbon cable, 1x 90° SMA adapter
