OSD with real-time telemetry data
The Fusion can show you real time- telemetry based data of your drone in the OSD. You need to be
connected to the Crossfire/ Tracer over WiFi (direct connection or by Cloud) and need a source for the
Voltage information like an FC or a Unify Evo, Core Pro or the in-build voltage sensor of the Crossfire/
Tracer receiver. Once the connection is established and running, you will see the data in your OSD:
Note: for this feature to work properly you should use the WiFi direct connection to the Crossfire/ Tracer.
As a safety feature the Fusion requires you to be on the same frequency as the Vtx. To ensure this, Vtx
Auto mode should be active while the VTX is connected to the Crossfire/ Tracer RX by CRSF or SmartAudio.
Otherwise the OSD will not show the telemetry data.
If you use a VTX that is not connected to the Crossfire/ Tracer RX the OSD will show up (except for GPS
data).
