  • Page 1 I Series (G2) Stove User Guide PLEASE RETAIN THIS GUIDE FOR FUTURE REFERENCE EN 13240:2011 +A2:2004 BK530 Rev 15 ISSUE DATE : 1/03/2017...
  • Page 2 Your Arada stove is built to the highest standard of craftsmanship using the best materials and the most modern equipment available. It is a highly efficient and sophisticated piece of ma- chinery and when properly installed and operated it should provide a lifetime of heating satis- faction.

  • Page 3: Table Of Contents

    I Series G2 Stove User Guide Contents Warnings ..................4 Health and Safety .................... 5 Smoke Control Areas ..................5 Recommended fuels Wood ....................6 Mineral Smokeless (Solid fuel) ................ 6 Before using your stove ..................7 Air inlet controls ..................8 Location and operation of the controls ............

  • Page 4: Warnings

    This will result in an over firing situation and will lead to severe damage to the stove and flue system. Ignoring the warnings could lead to damage/injury to persons and/or property. Arada Ltd will not be responsible for any consequential or incidental loss or injury however caused. Page 4...

  • Page 5: Health And Safety

    I Series G2 Stove User Guide 1.1 Health and Safety Please consult health and safety guidelines for advice on handling heavy and / or large items. 1.2 Smoke control areas (The Clean Air Act 1993 & Smoke Control Areas) Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a smoke control area.

  • Page 6: Recommended Fuels

    Arada recommends the use of approved smokeless fuels which have been deemed suitable for use on closed appliances including multi fuel stoves. For additional advice on fuels, please refer to The Solid Fuel Association (www.solidfuel.co.uk)

  • Page 7: Before Using Your Stove

    I Series G2 Stove User Guide 3 Before using your stove Arada stoves are designed to be operated with the fire door(s) closed at all times, apart from refuelling (when alight) or cleaning (when cold). Never leave the appliance unattended for an extended length of time with the door(s) open.

  • Page 8: Air Inlet Controls

    I Series G2 Stove User Guide 4 Air inlet controls Figure 3: I Series air inlet controls (freestanding model shown). 4.1 Location and operation of the controls Your stove has two air inlet controls. The primary air control is on the right, the secondary air control is on the left.

  • Page 9: Lighting Your Stove

    I Series G2 Stove User Guide 5 Lighting your stove 5.1.1 Smoke control areas Please check whether your dwelling is located in a smoke control area before installation or use. Please check with your local authority or https://www.gov.uk/smoke-control-area-rules. 5.1.2 Fuel overloading The maximum amount of fuel used should not be excessive, overloading can cause excess smoke.

  • Page 10: Burning Solid Fuels

    I Series G2 Stove User Guide about 10mm. This will aid flue draw during the initial lighting of the fire. The flue temperature and draw should be established after five minutes and the kindling reduced to form an ember bed. Carefully load the stove with well seasoned wood and fully close the fire door.

  • Page 11: Warning-Fume / Smoke Emissions

    I Series G2 Stove User Guide 5.4 Warning—Fume / Smoke emissions Properly installed, with a suitable flue or chimney, operated and maintained correctly, this appliance will not emit fumes into the dwelling. Occasional fumes when de-ashing and refuelling may occur. However, persistent fume emission is potentially dangerous and must be investigated by an approved / registered installer.

  • Page 12: Further Information For All Stove Owners

    I Series G2 Stove User Guide 6 Further information for all stove owners 6.1 Reduced burning (slow combustion) When wood is burnt slowly in a closed appliance, (eg.air controls at the minimum setting) it produces moisture and tar, which will create condensation and deposits in the chimney. This effect can be minimised by burning hard for a short period, fifteen to twenty minutes twice a day.

  • Page 13: Over Firing

    6.5 Replacement parts Genuine replacement parts or accessories can be ordered from your local stove dealer or online direct from Arada at www.aradastovesandspares.com Please note that the fitting of many third-party / unofficial parts to your stove will invalidate its guarantee.

  • Page 14: Ash Removal

    6.7 Multi fuel or Flexifuel grates The grate system in your Arada stove is comprised of a series of reciprocating cast iron bars seated on a pivoted comb. These should come pre-assembled in your new stove. All bars in the grate are identical, but every other bar is turned 180 degrees, with the ends of the bars marked "H"...

  • Page 15: How Heat Is Delivered By Your Stove

    7 How heat is delivered by your stove 7.1 Radiant heat All Arada stoves radiate heat into the room. The radiated heat is most intense at the front of the stove, especially through the door glass and less intense the further you move away from the stove.

  • Page 16: Care For Your Arada Stove

    I Series G2 Stove User Guide 8 Care for your Arada stove The need for regular maintenance on your stove will ensure, safe and efficient use of your appliance. The following item listing should be checked and inspected by a competent person or engineer on a regular basis.

  • Page 17: Throat Plate

    I Series G2 Stove User Guide 8.3 Throat plate The throat plate can be removed from the stove, by lifting the throat plate up and removing the rear liner, this will then allow the rear of the throat plate to swing down. Disengage the front lip of the throat plate from the upper location bracket.

  • Page 18: Further Resources / Information

    I Series G2 Stove User Guide 9 Further resources / information Arada Technical Support  01297 632052 technical@aradastoves.com www.aradastoves.com/support Competent Person Schemes  www.gov.uk/guidance/competent-person-scheme-current-schemes-and-how-schemes- are-authorised Solid Fuel Association  www.solidfuel.co.uk Document J Building Regulations (Combustion Appliances)  www.planningportal.gov.uk The National Association of Chimney Sweeps (NACS) ...

  • Page 19: Guarantee

    I Series G2 Stove User Guide 10 Guarantee When you buy an Arada stove, you are not only buying a first class appliance, you are receiving a commitment from us to look after you and your appliance. 10.1 Guarantee If any part of the main body of the stove fails due to a manufacturing or material defect during the guarantee period that applies in respect of the relevant stove (as set out below), Arada will, at its sole discretion, repair or replace your Arada stove, for no charge.
  • Page 20 I Series G2 Stove User Guide Stoves not purchased from an approved Arada dealer will not be covered by this guarantee. Your stove must be installed in the UK for this guarantee to be valid. Stoves installed outside of the UK will not be covered by this guarantee.

  • Page 21: General

    I Series G2 Stove User Guide 11. The guarantee is only valid where any spare parts used are supplied by Arada or an approved Arada dealer. The use of spares other than those supplied by Arada Limited shall invalidate the guarantee. Parts can be purchased through an approved dealer or directly from Arada, online at www.aradastoveandspares.com.
  • Page 22 I Series G2 Stove User Guide Notes Page 22 BK 530 Rev 15...
  • Page 23 I Series G2 Stove User Guide Notes BK 530 Rev 15 Page 23...
  • Page 24 I Series G2 Stove User Guide AFFIX DUPLICATE STOVE DATA LABEL HERE Arada Ltd The Fireworks, Weycroft Avenue Axminster, Devon EX13 5HU United Kingdom www.aradastoves.com www.aradastovesandspares.com T: +44 (0)1297 632 050 Page 24 BK 530 Rev 15...
