motogadget mo.hub Instruction Manual page 13

8) Insert the plug of the OEM speedometer (not tachometer!) In the with motogadget
Insert vehicle plug. The second OEM instrument plug (if available) with
Protect heat shrink tubing from splash water.
9) The eyelet of the motogadget battery connection cable with the battery-plus connection terminal
connect
10) Connect the battery (fi rst plus, then minus)
11) Install the tank and seat
9.3 BMW Modells with CAN Bus
9.3.1 Vehicletype identifi cation
BMW models from 2010 - 2014 a 6 pin instrument plug with the dimensions of
approx. 14.5x23.5x40mm, are equipped with a CAN bus for communication between control unit
and instrument.
9.3.2 Connection of the vehicle-specifi c plug to the mo.hub
mo.hub
motogadget BMW CAN Fahrzeugstecker
Port Nr.
1
2
3
F
G
(4005101)
rot
braun
schwarz
blau
lila
