motogadget mo.hub Instruction Manual page 12

9.2 BMW modells with LIN Bus
9.2.1 Fahrzeugtyp Identifi zierung
BMW models from 2015 with a 6 pin instrument plug with dimensions of
approx. 9x10x22mm, are equipped with a LIN bus for communication between control unit and
instrument.
9.2.2 Connecting the vehicle-specifi c plug and the battery cable to the mo.hub
mo.hub
motogadget BMW LIN Fahrzeugstecker
Port Nr.
1 motogadget Batterieanschlusskabel (4005102) von Batterie Plus
3 motogadget Stecker (4005100) Kabel schwarz
4
9.2.3 Installation
1) Jack up vehicle, remove seat and tank, disconnect battery (fi rst minus, then plus)
2) Unscrew OEM instrument, unplug connector, unscrew OEM instrument carrier.
3) attach the motogadget instrument to the vehicle-specifi c motogadget retaining plate and
connect the tail cable of the motogadget instrument to mo.hub
4) Connect motogadget vehicle-specifi c plug and battery cable to mo.hub
5) Screw the motogadget retaining plate with instrument to the fork bridge with the OEM screws.
6) Attach mo.hub to the upper frame tube with cable ties, avoiding collision
pay attention to mo.hub housing and tank.
7) motogadget battery connection cable, OEM instruments connector plug and motogadget
Instuments Lay the cable free of kinking and abrasion to the mo.hub and cable with cable ties
attach to the frame. Allow enough play for steering movements.
motogadget Stecker (4005100) Kabel rot
