- Page 1 Instruction Manual mo.hub V1.0...
- Page 2 Thank you very much for purchasing a high quality motogadget product - Made in Germany. Please read the following information and recommendations thoroughly and follow these in- structions during installation and use of the instrument. No liability shall be assumed by mo-...
- Page 3 In this regard, we refer to our General Terms of Business and Delivery, which are published at www.motogadget.com. Should a return of the received delivery be agreed, please note that we only take back goods in their original packaging. The mo.unit and its accessories must be returned within the legal period of time and without any traces of use.
- Page 4 TIVE TERMINAL AND THEN THE POSITIVE TERMINAL. FOR RECONNECTION PROCEED IN THE REVERSE ORDER. • USING THE MO.HUB WITH PLUS POLE CONNECTED TO VEHICLE FRAME (OLDER ENGLISH MOTORCYCLES) IS NOT POSSIBLE. • INSTALLATION AND ELECTRICAL CONNECTION OF THE MO.HUB MAY ONLY BE CARRIED OUT BY A CERTIFIED MOTORCYCLE TECHNICIAN.
- Page 5 The mo.hub is a universal data interface between vehicle and motogadget instrument or smartphone. Compatible vehicles with BUS or OBD interface are connected to the mo.hub by a supplied vehicle-mounted plug (Plug & Ride). For vehicles without interfaces, the required signals (tachometer, speed, control lights, etc.) must be tapped individually and connected to the mo.hub.
- Page 6 Overview area of Bluetooth Antenna- serial no. angeb do not cover with metal (important for support requests) terminal mouning holes for Status LED plug-in / relase connecting cabel by phusing marking cable cover orange inserts with a screw driver blade...
- Page 7 6 Mounting the cable cover & cable guide M3x16 countersunk cable ties...
- Page 8 Mounting options cable ties M4 screws...
- Page 9 8. Connecting motogadget instruments to the mo.hub 8.1 motoscope mini and combi-frame or handle bar clamp mo.hub motoscope mini combi-frame Lenkerklemme Port Nr. Kabelfarbe Kabelfarbe Kabelfarbe orange | gelb | violett schwarz orange | blau weiß gelb weiß grün schwarz...
- Page 10 8.2 motoscope tiny und motoscope classic mo.hub motoscope tiny motoscope classic Port Nr. Kabelfarbe Kabelfarbe schwarz schwarz | weiß-grün braun lila gelb orange weiß grün grün weiß grau gelb weiß-orange blau blau weiß-gelb...
- Page 11 Blinker L (+12V) Blinker R (+12V) Neutral (GND) ABS (+12V) Öltemperatur Sensor (motogadget Artikel 9001005 / 9001007 / 9001002) Öldruckschalter (GND) Lufttemperatur Sensor (motogadget Artikel 1005090) Wassertemperatur Sensor (motogadget Artikel 9001005 / 9001007 / 9001002) Fahrzeug-Tanksensor (0-500 Ohm - GND) Drehzahlsignal (Primärkreis Zündspule)
- Page 12 7) motogadget battery connection cable, OEM instruments connector plug and motogadget Instuments Lay the cable free of kinking and abrasion to the mo.hub and cable with cable ties attach to the frame. Allow enough play for steering movements.
- Page 13 8) Insert the plug of the OEM speedometer (not tachometer!) In the with motogadget Insert vehicle plug. The second OEM instrument plug (if available) with Protect heat shrink tubing from splash water. 9) The eyelet of the motogadget battery connection cable with the battery-plus connection terminal connect 10) Connect the battery (fi...
- Page 14 7) OEM instrument connector and motogadget instrument cable kink and scuff-free Lay to the mo.hub and secure the cables to the frame with cable ties. Suffi cient Allow game for steering movements. 8) Insert the plug of the OEM speedometer into the vehicle with motogadget plug.
- Page 15 11 Return and Complaint Before sending your mo.hub to us for technical review, please contact Technical Support. Visit our website and follow the instructions under “Support”. For support requests, we always need the serial number (sticker top mo.hub, your smartphone model used, the app version (see main menu under “About”).) To return the item, please follow the instructions under “Service”...
-
Page 16: Fcc Compliance Statement
Regulations PRODUCT INFORMATION: Manufacturer: motogadget GmbH Model: mo.unit blue FCC ID: 2AIF8-4005000 21495-4005000 FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 17 (1) Cet appareil ne doit pas provoquer d’interférences et (2) cet appareil doit accepter toute interference, y compris celles pouvant causer un mauvais fonctionnement de l’appereil. Das motogadget Team wünscht Ihnen eine angenehme und sichere Fahrt sowie viel Spaß mit Ihrem neuen mo.hub.
