Task Force Tips VIT Instructions For Installation, Safe Operation And Maintenance page 7

8.0 EXPLODED VIEW AND PARTS LIST
26
29
27
28
27
31
30
26
ITEM DESCRIPTION
1 GAUGE BUMPER
2 THREAD PROTECTOR RING
3 3/16" TORLON BALL
4 SPRING
5 CAM DETENT SCREW
6 VIT FRONT RING LABEL
7 TEFLON WEAR RING
8 FRONT END - 7/8" TIP
FRONT END - 15/16" TIP
FRONT END - 1.0" TIP
FRONT END - 1 1/8" TIP
FRONT END - 1 1/4" TIP
FRONT END - 1 3/8" TIP
FRONT END - 1 3/16" TIP
9 O-RING-227
10 BALL SEAT VALVE
11 DELRIN VALVE BALL
12 DETENT VALVE BODY
13 TRUNNION - LEFT
14 TRUNNION - RIGHT
15 TEFLON TRUNNION SHIM
16 O-RING-118
* - CONSULT FACTORY FOR SPECIAL THREADS
©Copyright Task Force Tips, Inc. 2009-2015
22 21
25
24
23
12
13
37
QTY PART #
1 P177
1 P175
2 V2120-TORLON
2 VM4195
2 HD790
1 P163
2 P172
1 P181*
P182*
P183*
P184*
P185*
P186*
P187*
1 VO-227
2 P104
1 P103
1 P110
1 P120L
1 P120R
2 P170
2 VO-118
20
19
18
17
16
15
14
10
11
10
9
32
33
34
35
36
ITEM DESCRIPTION
17 .243"TORLON BALL
18 DETENT SPRING
19 3/8-24 X 3/4 BUTTON HEAD
20 TRUNNION DRIVER
21 3/16 X 9/16 HDP SPIROL
22 HANDLE SUBASSEMBLY
23 STREAM STRAIGHTENER
24 ANTI GG RING VO
25 O-RING-141
26 3/16" SS BALL
27 1/4-28 X 3/16 SOCKET SET SCREW
28 COUPLING 1.5"F ROCKERLUG
29 1.5" GASKET
30 COUPLING 2.5"F ROCKERLUG
31 2.5" GASKET
32 10-32 X 1/4 SOCKET SET SCREW
33 GRIP SPACER HANDLINE
34 PISTOL GRIP - BLACK
35 WASHER
36 3/8-16 X 1 SOCKET HEAD SCREW
37 3/8-16 X 5/16 SOCKET SET SCREW
38 FRONT RING VO 1.5"M
* - CONSULT FACTORY FOR SPECIAL THREADS
7
8
7
7
38
6
QTY PART #
2 VB243TO
2 HM770
2 VT37E24BH750
2 HX650
2 V2005
1 HX920
1 P116
1 P147
1 VO-141
38 V2120
1 VT25-28SS187
1 H694*
1 V3130
1 P198*
1 V3190
2 VT10-32SS250
1 HM693-H
1 HM692-BLK
1 VM4901
1 VT37-16SH1.0
1 VT37-16SS312
1 P150*
LIN-050 July 2, 2015 Rev01
5
4
3
2
1
