1.0 MEANING OF SIGNAL WORDS

A safety related message is identifi ed by a safety alert symbol and a signal word to indicate the level of risk involved with a
particular hazard. Per ANSI standard Z535.6-2006, the defi nitions of the four signal words are as follows:
DANGER
WARNING
CAUTION
NOTICE

2.0 SAFETY

DANGER
WARNING
WARNING
WARNING
WARNING
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
©Copyright Task Force Tips, Inc. 2002 - 2011
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
NOTICE is used to address practices not related to personal injury.
Do not use AC current to operate the Ball Intake Valve RC or the Jumbo Ball Intake Valve
RC. The Ball Intake Valve RC and the Jumbo Ball Intake Valve RC are 12 or 24VDC systems
ONLY! Using the wrong power source could cause electrocution, resulting in death or serious
injury.
Injury or death can result from burst hoses and fi ttings. Be sure the pressure relief valve is set
at the proper pressure for the type of hose and equipment you are using. See NFPA 1961 and
NFPA 1962.
Injury or death may occur by attempting to use a damaged Ball Intake Valve. Before using the
valve inspect it for damage resulting from:
• Failure to drain valve followed by exposure to freezing conditions
• Exposure to temperatures in excess of 160 degrees F
• Missing parts, physical abuse
This equipment is intended for use by trained personnel for fi refi ghting. Its use for other
purposes may involve hazards not addressed by this manual. See appropriate guidance and
training to reduce risk of injury.
Kinks in supply hose may reduce water fl ow and cause injury or death to persons dependant
on water fl ow. When this valve is used on a hydrant or fi re truck it is recommended that it be
used with an elbow to minimize risk of hoseline kinks.
The electric Ball Intake Valve RC and the Jumbo Ball Intake Valve RC may be remotely operated.
The electric drives are current limited but may still produce enough force to cause injury. Keep
hands and fi ngers away from pinch points on the valve.
Do not use the manual override hand wheel while the electric controls are in operation. The
electric drives produce enough torque to cause injury.
The Ball Intake Valve RC and the Jumbo Ball Intake Valve RC have current limiting capabilities
which stops the motor if an obstruction is encountered. The Ball Intake Valve RC and the
Jumbo Ball Intake Valve RC must be installed as instructed using the correct controls and
electrical boxes. Failure to do so will result in damage to the electric motor and loss of current
limiting controls. This may result in injury.
Maximum operating pressure for the Ball Intake Valve models 300 PSI (20 bar). Do not exceed
300 PSI on either side of the Ball Intake Valve. Maximum operating pressure for Jumbo Ball
Intake Valve models 250 PSI (17 bar). Do not exceed 250 PSI on either side of the Jumbo Ball
Intake Valve.
Valve must be properly connected. Mismatched or damaged connectors may cause leaking or
uncoupling under pressure and could cause injury.
The Ball Intake Valve may become damaged if it is allowed to freeze while containing water.
Always drain after use to avoid damage and possible loss of use.
3
LIA-200 July 30, 2011 Rev13
