- Page 1 USER MANUAL inspire...
- Page 2 by e-bility GmbH Dieselstraße 28 53424 Remagen, Germany www.kumpan-electric.com 1st edition, Remagen, Sept. 2020 © 2020 e-bilty GmbH All rights reserved. This user manual is for the following models: • 54 inspire (25/45 km/h)
-
Page 3: Table Of Contents
Contents Safety instructions Kumpan Key app P. 16 P. 6 Rearview Mirror P. 17 Important information P. 6 Overall View Left P. 18 Driver’s licence categories P. 6 Overall View Right P. 19 Check & Start P. 7 View from the Front and Rear P. - Page 4 Contents Display/Operation Main Stand P. 51 P. 35 Side Stand P. 51 Retracting P. 52 Display/Touch Screen P. 36 Feet Rests P. 53 Display / Touch Screen – View while Driving P. 37 Operating the Touch Screen P. 38 Maintenance and Care P.
- Page 5 Foreword Congratulations, you’re the proud owner of a Kumpan 54 inspire! We hope you have loads of fun with your new two- wheel companion. This manual primarily serves to provide you with instructions and references to allow you to handle your Kumpan in a safe and careful way.
-
Page 6: Safety Instructions
Safety Instructions Important information Driver’s Licence Categories The scooter is designed for operation on public roads with a driver and a The vehicle can be approved for use on public roads and may be operated with passenger. the following licence permit categories: Any improper use of the vehicle will void both the manufacturer’s warranty and statutory warranty. -
Page 7: Check & Start
Safety Instructions DANGER MAX. 195 Kg Check & Start Loading & Unloading Wet & Slippy Conditions Before every trip, inspect the scooter Always load the Kumpan carefully and Transporting people or animals on Exercise particular caution when to make sure it is safe for use on the beware of overloading. -
Page 8: Cold Weather
Safety Instructions DANGER Cold Weather Body & Soul Spirit & Knowledge After cleaning the scooter, the brakes Before every trip, make sure that all The taking of certain medicines, Never stand up while driving. Always should carefully be “braked dry” at moving parts operate without fault, alcohol, non-prescription drugs or drive with focus and care. -
Page 9: Law & Order
Safety Instructions DANGER Law & Order Defects & Accidents Most accidents are caused by Always observe the road signs as Try to never drive over or hit objects works, inform the personnel of your inexperience, which is why you well as national and/or local traffic that might damage the vehicle or workshop about any faults. -
Page 10: Clothing For Head & Body
The use of accessories not approved appropriate and tight-fitting clothes as keys and ballpoints on your body; Kumpan. by Kumpan electric might void both suitable for the weather conditions. they might be dangerous in the event Ensure that the accessory is properly the manufacturer’s warranty and... -
Page 11: Checklist Before Your First Drive
Checklist before your first drive Everything ready? Everything set? Go explore! When using your vehicle, you must carry the following identification documents and papers with you: - ID card/passport - Driver’s licence/moped certificate - Insurance certificate - Insurance tag - Vehicle certificate of conformity (CoC) - Page 12 Checklist before your first drive 2.6 bar 2.2 bar Did you read through the Quick • Battery charged and plugged in the Mirrors mounted and set correctly? Proper tyre pressure: Starter Guide/Manual? front battery slot? Under one-person load: Insurance tag (54 inspire) installed? 2.2 bar front 2.6 bar rear Under full load (two persons):...
- Page 13 Checklist before your first drive Do all signalisation and lighting Checked the brake system for proper Helmet and protective clothing on? Feet rests extended if you’re systems work properly? functioning – confirmed the brake planning on bringing a passenger? pressure point? Regularly check all signalisation and lighting systems for proper functioning, if necessary with a...
-
Page 14: The Kumpan 54 Inspire
The Kumpan 54 inspire Detailed look at the components of your Kumpan... -
Page 15: Bluetooth Key
The Kumpan 54 inspire Bluetooth key Start-Stop button 1. Switch on your Kumpan 3. Start-Stop Button 2. Switch off your Kumpan... -
Page 16: Switching The Kumpan On And Off
The Kumpan 54 inspire START ZUM STARTEN BESTÄTIGEN 08:22 Uhr · 01.01.2019 MENU Switching the Kumpan Note On and Off • With our “Kumpan Key” app, You can only switch on the scooter if: • Press the Start-Stop button Cruise control only works after both you can also teach your smartphone •... -
Page 17: Rearview Mirror
The Kumpan 54 inspire Rearview Mirror Installation: Place correct Turn the mirror clockwise into Adjust the mirror before every trip rearview mirror on both sides of the thread and adjust it. When and check the setting while sitting in the scooter, into the thread on the looking from the top, the arm of the correct position on your Kumpan. -
Page 18: Overall View Left
The Kumpan 54 inspire Overall View Left 1st Headlamp 2. Rearview Mirror 3. Seat 4. Handle 5. Hub motor 6. Main Stand 7. Feet rests 8. Side reflector... -
Page 19: Overall View Right
The Kumpan 54 inspire Overall View Right 1st Leg compartment with beverage holder 2. Glove compartment with 12 V socket 3. Disc brake front wheel 4. Side reflector 5. Feet rests 6. Chassis number (VIN)/type plate 7. Disc brake rear wheel... -
Page 20: View From The Front And Rear
The Kumpan 54 inspire View from the Front and Rear 1. Turn signal front 2. Brake lever front wheel 3. Brake lever rear wheel 4. Cruise control/touch screen display 5. Gas handle 6. Rear light/brake light 7. Turn signal rear 8. -
Page 21: Switch Unit Left
The Kumpan 54 inspire MAX. MIN. Switch Unit Left 1. Full-beam/anti-glare light switch 2. Turn signal switch 3. Horn 4. Filling level indicator brake rear... -
Page 22: Switch Unit Right
The Kumpan 54 inspire MAX. MIN. Switch Unit Right 1. Emergency-Off switch/warning lights 2. Control pad 3. Cruise control* 4. Filling level indicator brake front *The cruise control can only be switched on after both brakes have been applied once. -
Page 23: Glove Compartment/Leg Compartment
The Kumpan 54 inspire Glove Compartment/ Leg Compartment 1. Glove compartment 2. 12 V socket (max. 4.5 A) 3. Lighting 4. Lock to unlatch the seat 5. Leg compartment with beverage holder *Press these spots to open the glove and leg compartments. -
Page 24: Seat/Battery Compartment
The Kumpan 54 inspire Seat/Battery Compartment 1st Seat 2. Seat lock* *Press this symbol at the top-left of the display to open the seat. Note: Alternatively, you can open the seat using the lock in the glove compartment. - Page 25 The Kumpan 54 inspire Seat/Battery Compartment 1st Battery compartment (3 slots) 2. Battery/battery slot 3. Battery transport slots or stowage space 4. Storage compartment *This symbol appears at the top-left of the display when the seat is open...
- Page 26 Battery Kraftpaket 2.0 How to charge your Kumpan...
-
Page 27: Technical Properties
Battery Kraftpaket 2.0 The battery is the centrepiece of your scooter. Make sure to keep the contacts clean and keep the battery away from humidity and moisture. If the battery is not placed in the scooter, place the cover cap onto the contact in the battery compartment. -
Page 28: Battery Displays
Battery Kraftpaket 2.0 Note Battery Displays A new battery initially fails to reach A display shows you the charge its full capacity, the full charge status at the top of the Power Pack. status only shows after several charging cycles. An additional LED strip uses a traffic- light system to visualise the charge status (red, yellow, green). -
Page 29: Placing And Removing The Power Pack
Battery Kraftpaket 2.0 Placing and Removing the Power Pack The Kumpan 54 inspire is delivered with one Power Pack 2.0 by default. After opening the seat (see pages 23/34/39/47), you can place your Power Pack into the vehicle. Plug the Power Pack into the matching slot. Slight pressure on the handle paired with the weight of the Power Pack will lock it into the slot and connect it to the vehicle. - Page 30 Battery Kraftpaket 2.0 To remove the Power Pack 2.0 from the vehicle, you first pull the handle upwards to unlock. Afterwards, you can pull it up out of the battery compartment. After 2–3 weeks at the most, place your Power Pack 2.0 back into your Kumpan to recharge the back-up battery for the on- board electronics.
-
Page 31: Storage
Battery Kraftpaket 2.0 NOTE Storage • Please do not store the battery If you don’t use your Kumpan for standing up a longer period, you should always make sure that the battery is charged • Store the battery in a dry place, to at least 50%. -
Page 32: Charging Unit
Battery Kraftpaket 2.0 DANGER General information on usage: Charging Unit • Do not charge on surfaces Technical Properties: Our charging unit was specially sensitive to heat. developed for the Power Pack 2.0. • Prevent contact between the charging Input voltage: 180–240 V/50 Hz The upper side of the charging unit unit and water, acids, or bases. -
Page 33: Charging Outside Of The Vehicle
Battery Kraftpaket 2.0 Charging Outside of the Vehicle Put down your Power Pack 2.0 so that you can access the connection socket. Afterwards, connect the charging cable of your charging unit to the Power Pack. Now, all you need to do is connect the charging unit with a 220 V domestic power socket and switch on the charging unit. -
Page 34: 12 V Back-Up Battery
The back-up battery is fixed inside the control unit of your scooter and cannot be removed. Replacements are only possible via the Kumpan electric Service. If the back-up battery happens to be drained after a longer standstill, you can... -
Page 35: Display/Operation
Display/ Operation The display of your Kumpan... -
Page 36: Display/Touch Screen
Display/ Operation 08:22 Uhr · 01.01.2019 MENU Display/Touch Screen 1. Status seat 2. Status topcase (with electric topcases) 3. Menu 4. Battery level 5. Time/date 6. Driving mode/quick overview 7. Speed display 8. Consumption display... -
Page 37: Display / Touch Screen - View While Driving
Display/ Operation km/h Display / Touch Screen – View while Driving 1. Digital display left (can be programmed) 2. Speed display (analog representation) 08:22 Uhr · 01.01.2019 MENU 3. Full beam 4. Anti-glare light 5. Cruise control 6. General warning lights RED: Defect –... -
Page 38: Operating The Touch Screen
Display/ Operation km/h Operating the Touch Screen The display also comes with a touch function. You can simply 08:22 Uhr · 01.01.2019 MENU operate the individual elements by tapping on the display. NOTE The display should only be operated while the vehicle is not moving. -
Page 39: Scooter Functions
Display/ Operation km/h km/h LADEKLAPPE BITTE LADEKLAPPE SCHLIEßEN 08:22 Uhr · 01.01.2020 MENU 08:22 Uhr · 01.01.2020 MENU 08:22 Uhr · 01.01.2020 MENU Scooter Functions Menu Notifications/Notices Opening the Seat: Menu navigation: confirm with “OK” Tap on the seat symbol Tap on the menu item Tap “Back”... -
Page 40: Menu Items
Display/ Operation FAHRMODUS ALLGEMEINE km/h EINSTELLUNGEN SYSTEMINFO MENU BEENDEN 08:22 Uhr · 01.01.2019 MENU Menu items The “Menu” view has the following items and respective sub-menus: 1st Driving Mode 2. General Settings 3. System info 4. Close menu... -
Page 41: Driving Mode
Display/ Operation Driving Mode In the menu item “Driving Mode”, you can make changes to km/h the throttle response, motor power, and recuperation. You can RAIN choose between the following driving modes: ECO: ECO: Energy-saving mode, maximum recuperation, gentle throttle response, ideal for maximum range. -
Page 42: General Settings
Display/ Operation km/h General Settings In the menu item “General Settings”, you can configure your Kumpan. 08:22 Uhr · 01.01.2020 MENU You have the following options: Sounds: Your Kumpan gives audio feedback when signalling turns. You can adjust the volume in the menu or deactivate sounds completely. - Page 43 Display/ Display/ Operation Operation NOTE Time/date: The remaining range calculated by Kumpan is an approximation, which Your scooter automatically receives the correct date and time via radio signals. If the clock on your scooter happens to be incorrect, you can set the time here. depends on numerous factors.
-
Page 44: System Info
Display/ Operation km/h 08:22 Uhr · 01.01.2020 MENU System info In the menu item “System info”, you will find the VIN number and software version of the individual control units. -
Page 45: Control Pad Operation
Display/ Operation Control Pad Operations Operate the display using the control pad on the right handlebar unit. -
Page 46: Quick Overview
Display/ Operation km/h 08:22 Uhr · 01.01.2019 MENU Enter Quick overview You can select the following items: Press the right or left arrow on the (Enter) of the control pad for 2 control pad to switch between the seconds to reset the value of the Trip - Driving mode various items in the quick overview. -
Page 47: Battery Display/Charging Status
Display/ Operation km/h km/h LADEKLAPPE BITTE LADEKLAPPE SCHLIEßEN 08:22 Uhr · 01.01.2019 MENU 08:22 Uhr · 01.01.2020 MENU 08:22 Uhr · 01.01.2020 MENU 08:22 Uhr · 01.01.2020 MENU Enter Enter Enter Enter Battery Display/Charging Status Opening the Seat Opening the Topcase Notifications/Notices Use the up arrow to reach the “Battery Use the up arrow to reach the “Open... -
Page 48: Menu
Display/ Operation FAHRMODUS ALLGEMEINE km/h EINSTELLUNGEN SYSTEMINFO MENU BEENDEN 08:22 Uhr · 01.01.2019 MENU Enter Enter Enter Menu Confirm with Enter to access the Confirm with Enter to select an To get to the “Menu” item, go back menu. individual menu item. up to the quick overview item. -
Page 49: Operating/Driving
Operating/Driving Helpful tips to operate your Kumpan... -
Page 50: Safe Driving And Stopping
Safe Driving and Stopping Handlebar lock For safety reasons, the connection By turning the throttle, your Kumpan Your Kumpan 54i is fitted with an between the key and the scooter is starts and accelerates. electric handlebar lock. The handlebar only established after a movement lock automatically releases after of the key is registered. -
Page 51: Main Stand
Operating/Driving Main Stand Side stand* PLEASE NOTE Stand to the left of the scooter to Make sure that both support points Always check whether the scooter is Hold the scooter by the left handlebar apply the main stand. of the main stand touch the surface. in a stable position, resting on solid grip and the left side of the handle to ground. -
Page 52: Retracting
Operating/Driving Retracting DANGER New tyres primarily tend to lose The brake pads and brake discs only New tyres have a smooth surface grip on wet roads and with extreme work optimally after a certain start- which need to be roughened up cornering, risk of falling! up period. -
Page 53: Feet Rests
Operating/Driving Feet Rests The feet rests are needed when To fold up the rests, push them into transporting a passenger. If the rests the panelling as far as they go. are not being used, fold them back up to prevent damage and injury. The feed rests are folded down by pressing on them. -
Page 54: Maintenance And Care
Maintenance and Care How to care for and service your Kumpan... -
Page 55: Brakes
Maintenance and Care Brakes DANGER If you fail to notice a pressure Pull the front and rear brake lever one A clear brake pressure point should be point or if you can push the scooter after the other to check the brake noticeable when pulling both levers. -
Page 56: Brake Fluid Level
Maintenance and Care MAX. MIN. brake fluid level DANGER If the brake fluid level falls below Regularly check the brake fluid level The brake fluid level must fall the minimum level, safe operation using the sight panel on the brake between the max. -
Page 57: Chassis
Maintenance and Care Chassis Setting the spring pre-load: You can set the spring pre-load of the rear shock absorber (increasing spring pre-load “harder spring” in the direction of the arrow). Adjust the chassis when driving with 2 persons or carrying a load by tightening the spring pre-load. -
Page 58: General Instructions
Maintenance and Care General Instructions PLEASE NOTE To reliably prevent rust from forming, Never aim a direct water jet on the Only use suitable cleaning and care we recommend thoroughly cleaning following components: agents (e.g. plastic cleaner, seat and drying the vehicle after driving in cleaner) and a soft sponge. - Page 59 Maintenance and Care DANGER Brake discs that are wet after a After washing your Kumpan, rinse Make sure to clean your Kumpan wash, driving in the rain or puddles with clean water to remove any regularly, especially over the winter impair the functioning of the brakes.
-
Page 60: Vehicle And Battery Storage Periods - Winter Break
Maintenance and Care Vehicle and Battery Storage Periods – Winter Break NOTE If you do not use your Kumpan for a longer period or store it in the winter months, please observe the following: • Thoroughly clean the vehicle before a longer period of standstill. •... -
Page 61: Troubleshooting
Troubleshooting How to easily identify and solve errors... - Page 62 Troubleshooting Error Possible causes Troubleshooting • You switch on the scooter, pull on the gas – but • Insufficient battery charge. • Connect your Power Pack to the charging unit the scooter just stands there. and charge it (see page 33 and the next). •...
- Page 63 Troubleshooting Error Possible causes Troubleshooting • The charge capacity of your battery is dwindling. • Park your scooter in a warm place (inside/garage). • Your battery is defective. • Visit a specialist workshop. • The battery cannot be charged. • The connection between the battery •...
- Page 64 Troubleshooting Code on display + description Possible causes Troubleshooting E114 – scooter short-circuit Software problems in the motor controller Briefly remove the battery from the vehicle and insert it again. If this doesn’t help, contact your Kumpan service partner or service@ebility.de E131 –...
-
Page 65: Technical Details
Technical Details The technical details of your Kumpan... - Page 66 Technical Details Motor Storage temperature approx. 10 to 15°C (ideal), possible range: -20 up to +60°C Model Brushless DC hub motor Charging current/charging time 6 A, 4.5 hours Maximum performance 3000 W Maximum efficiency ≥ 85% Charging Unit Max. torque 92 Nm at 560 RPM Type PBI48-8, IC controlled charging unit with...
- Page 67 Technical Details Chassis Dimensions Fork With spring and hydraulic support Length 1939 mm (without topcase) Spring strut Double spring strut with hydraulic Width 755 mm (without mirrors) support (adjustable spring pre-load) 779 mm (with mirrors) Height 1210 mm (without mirrors) 1352 mm (with mirrors) Wheelbase 1356 mm...
- Page 68 Technical Details 1356 1921 1939 all dimensions in mm...
- Page 69 Technical Details all dimensions in mm...
-
Page 70: Accessories
Accessories Kumpan offers the following accessories for your vehicle: 1. Topcase carrier 2. Topcase mechanical 3. Topcase electric 4. Crash bar 5. Side Stand For details and additional accessories, visit: www.kumpan-electric.com... -
Page 71: Key Safety Instructions
Safety Instructions Safety instructions The safety instructions have the following structure: SIGNAL WORD Danger type and source! Consequences of non-compliance. DANGER This combination of symbol and signal word points out a hazardous situation. Failure to observe the instruction can lead to death or serious injury and/or damages to property and the environment. - Page 72 Contact WE WISH YOU e-bility GmbH | Dieselstraße 28 | (D) 53424 Remagen A SAFE AND 0049 (0) 2642 - 999 800 info@ebility.de www.kumpan-electric.com PLEASANT DRIVE WITH Social Media YOUR KUMPAN! LinkedIn Facebook Instagram YouTube...
