6.3 MOTOR ASSEMBLY BIV RC & JUMBO BIV RC EXPLODED VIEW AND PARTS LIST
4
3
2
1
INDEX
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
©Copyright Task Force Tips, LLC 2002 - 2018
13
11
6
5
10
9
7
8
7
DESCRIPTION
1/4-28 X 5/8 SOCKET HEAD CAP SCREW
REDUCER COVER
BUSHING NYLON
38LINK ROLLER CHAIN
DRIVE SPROCKET 12 TEETH
BUSHING MOTOR
THIN WASHER
BIV SPROCKET 25 TEETH
3/8-16 X 3/4 BUTTON HEAD CAP SCREW
LOCK WASHER 3/8"
REDUCER HOUSING
CUP SEAL 1.0625 X .5625 X 1/4
STRAIN RELIEF PG11 .39 HOLE
6-32 X 5/16 LONG SHCS WITH HEAD SEAL
MOTOR SOCKET
O-RING-038 2-5/8 ID 1/16 C/S
GEAR MOTOR W/CRIMPED TERMINALS
MOTOR BOARD SUPPORT
KNOB
OVERRIDE KNOB LABEL
1/4-20 X ½ BUTTON HEAD CAP SCREW
MOTOR ENCLOSURE TUBE
CIRCUIT BOARD STANDOFF
VALVE MOTOR BOARD
MOTOR ENCLOSURE CAP
SMALLEY RING
18
17
15
16
1
14
12
21
19
QTY
6
1
1
1
1
1
2
1
1
1
1
1
1
4
1
2
1
1
1
1
2
1
3
1
1
1
13
26
25
16
24
23
22
20
PART #
VT25-28SH625
A1097
X252
AX1685
X253
X256
A1530
A1098
VT37-16BH750
VW375SSLOCK
A1096
Y4620
Y5205
VT06S32SH312
Y4615
VO-038
Y4600
Y4643
Z245
Y4176
VT25-20BH500
Y4641
Y5538
A5825
Y4642
V4295
LIA-200 March 20, 2018 Rev19
