- Page 1 Manual of the GL60 UAV Gimbal Light User’s Manual V1.0 2020.06.20 Catalogue Ⅰ. Gimbal Light series introduction Ⅱ.Disclaimers and warnings Ⅲ. The introduction of GL60 Ⅳ. The Gimbal Light Software Tutorial Ⅴ.The firmware update...
- Page 2 PTZ camera. The GL60 UAV Gimbal Lights is the best night partner for DJI M300 RTK drone. It has a fan - free fuselage to achieve a fully sealed design, providing excellent waterproof and dustproof performance, can work reliably in harsh weather conditions.
- Page 3 1. Dust cover 2. the DJI SkyPort V2.0 interface 3. Memory card slot 4. UAV 3-axis gimbal 5. The light export Product parameters The Prime version of GL60 Electrical interface DJI SkyPort V2.0 Size/mm L132*W110*H137 Weight/g The total power/w The LED power/w Luminous flux/lm 4000±3%...
- Page 4 1. Click DJI Pilot to enter the main interface. 2. Enter the main interface and the word Gimbal SearchLight 60 is displayed in the lower left corner, indicating that the LOAD identification of GL60 is successful. You can proceed to the next step and click manual flight.
- Page 5 4. Click the menu bar and click the third-party load option to enter the GL60 operation interface. 5. Click the button to display real-time data, and a status display box will pop up in the upper left corner of the main interface to observe real-time temperature, power and other parameter states of...
- Page 6 6. Click the switch button to control the on-off state of the light; Click the Twinkle button to turn on the flash mode. Slide the Brightness bar option to adjust the brightness of the GL60. 7.When H20 and GL60 are used simultaneously, the Pitch adjustment button, Roll adjustment button and Yaw adjustment button can be used to keep the spot in the center of the screen.
- Page 7 Ⅴ.The firmware update For firmware update of GL60 UAV Gimbal Light or download the latest version, please pay attention to www.gzczzn.com. If the Light cannot work properly due to the firmware update of UAV, please contact the local...
