- Page 1 ... print your plane | www.3DLabPrint.com User Guide rev. 2020/09 Fully 3d printable upgrade to short wing for Focke-Wulf Ta 152 C scale 1:12, wingspan 960 mm / 37.8 inch page...
- Page 2 ... print your plane | www.3DLabPrint.com Focke-Wulf Ta 152 C – fully printable update for Ta 125 version C - short wing Extensive hi-tech 3d structural reinforcement making the model very rigid while maintaining a lightweight airframe and exact airfoil even it’s just a plastic. This perfect and exact 3d structure is possible only thanks to additive 3dprinting technology.
-
Page 3: Recommended Setups
... print your plane | www.3DLabPrint.com General specifications (HP setup): 960 mm / 37.8 inch Wingspan: Lenght: 870 mm / 33.9 inch Height: 178 mm / 6.95 inch Wing area: 18 dm2 / 1.93 square foot Wing loading: 46 g/dm2 / 15.3 oz/square foot Center of gravity: 60 mm / 2.34 inch... - Page 4 ... print your plane | www.3DLabPrint.com Focke-Wulf Ta 152 C, History The Focke-Wulf Ta 152 was a World War II German high-altitude fighter-interceptor designed by Kurt Tank and produced by Focke-Wulf. The Ta 152 was a development of the Focke-Wulf Fw 190 aircraft. It was intended to be made in at least three versions the Ta 152H Höhenjäger („high-altitude fighter“), the Ta 152C...
- Page 5 ... print your plane | www.3DLabPrint.com Ta 152 C Centre of Gravity Wing area: 18 dm2 / 1.93 square foot 960 mm / 37.8 inch Wing span: page...
- Page 6 5. Assembly of printed parts 5.1 Wing assembly Ta 152 C Glue wing parts L1-L4 perfectly together. The new 3DLabPrint lock system will help you. Repeat for the right side. Glue both halves of the wing together. Use the CA glue, (position locks and pins will help you to align the parts), and use activator to speed up the glue curing.
-
Page 7: Servo Installation
... print your plane | www.3DLabPrint.com 5.2.1 Fuselage Ta 152 C update for rubber band Parts F4 and F2 can be printed in improved ACES version for fixing the wing assembly with rubber bands. Use 3mm carbon rod for improved rubber wing fixing. Don‘t glue carbon rod in part F4 for easy rubber change. - Page 8 ... print your plane | www.3DLabPrint.com Use power by your skill ! Our inovative motor holder can be used with various motors. Every motor should fit at universal printed holder with alluminium cross or 16 x 19 or 25 x 19 (new in this update) printed holder.
-
Page 9: Shopping List
... print your plane | www.3DLabPrint.com Shopping list Printing material: 0,65kg of PLA (optionally 150g of LW-PLA) 4 channel receiver for your RC system Motor: any motor for 3S - 6S Li-Pol with weight up to 100g EMAX MT 3510 600KV (for 6S setup)
