- Page 1 ... print your plane | www.3DLabPrint.com User Guide rev. 2020/04 Fully 3d printable VL Pyörremyrsky scale 1:12, wingspan 850 mm / 33.5 inch page...
- Page 2 ... print your plane | www.3DLabPrint.com VL Pyörremyrsky fully printable R/C plane for your desktop 3Dprinter Fully 3D printable RC model of the finish attack plane, specially designed to meet ACES and EPA aircombat requirements, but also as a cheap and easy to build RC model for everyday flying.
-
Page 3: Recommended Setup
... print your plane | www.3DLabPrint.com General specifications (HP setup): Wingspan: 850 mm / 33.5 inch Lenght: 750 mm / 29.5 inch Height: 170 mm / 6.7 inch Wing area: 15,9 dm2 / 1.61 square foot Wing loading: 31 g/dm2 / 15.3 oz/square foot Center of gravity: 60 mm / 2.34 inch... - Page 4 ... print your plane | www.3DLabPrint.com VL Pyörremyrsky (Wooden Messerschmitt), History On 26 November 1942 the Finnish Air Force ordered two Pyörremyrsky prototypes to be built. The aircraft were to be ready by May 1944. One prototype was later cancelled and only one aircraft was ever built.
- Page 5 ... print your plane | www.3DLabPrint.com Included: 1. STL 3d files Universal STL files designed to be used with desktop FDM 3d printers and slicer software as Simplify3D (recommended), CURA or MatterControl (these STLs are not compatible with Slic3r). 2. Factory files for Simplify3D slicer - preffered contains all the necessary settings to slice the models along with suggested bed layout.
- Page 6 ... print your plane | www.3DLabPrint.com 5. Slice on your own with CURA or MatterControl slicers If you for any reason don‘t like Simplify3D, there is always option to use another free slicer Please follow our Cura guide in the Help section of the website where you can find the basic single-wall profile.
- Page 7 ... print your plane | www.3DLabPrint.com VL Pyörremyrsky 60 mm Centre of Gravity Wing area: 15,9 dm2 / 1.61 square foot Lenght: 750 mm / 29.5 inch page...
- Page 8 ... print your plane | www.3DLabPrint.com Wing span: 850 mm / 33.5 inch page...
- Page 9 ... print your plane | www.3DLabPrint.com Step By Step PDF/VIDEO userguide Choose airplane at www.3Dlabprint.com, visit our Facebook for latest info. Basic requirments for VL Pyörremyrsky are 195/195/195 volume, nozzle 0.4mm recommended (0.35 or 0.5mm alternativelly). Heated bed recommended. Designed to be printed with LW PLA filament by Colorfabb.
- Page 10 ... print your plane | www.3DLabPrint.com option B Factory files Simplify3D (recommended): We prepared all you need in these files (FFF process settings, parts layout on bed, etc...) You can use these settings as a start point. Adjust according to your need (adapt for your printer), print single parts and so on...
- Page 11 ... print your plane | www.3DLabPrint.com option D CURA or MatterControl MatterControl and CURA are free and provide satisfactory results. The airframe is still strong enough, but don‘t expect the best quality. Both slicers lacks some very useful features, and finer settings, like multiple processes according to Z height, retraction options, layer start, etc.
- Page 12 ... print your plane | www.3DLabPrint.com 4. Print it Save the Gcodes to the SD card and insert into your printer. Prepare your printer and start printing, we prefer to use SD card rather than direct USB connection. Scaling the model will...
- Page 13 ... print your plane | www.3DLabPrint.com Enjoy the fun together! VL Pyörremyrsky VL Pyörremyrsky is the first of new LW Planes weights of printed parts series designed for easy and cheap flying. The build is simple even for a beginner. It’s very...
- Page 14 ... print your plane | www.3DLabPrint.com How to print LW-PLA? The basic print setup is almost the same as we use for standard PLA. The only difference is in extrusion multiplier set to 0.5 and turning off the retractions completely.
- Page 15 5. Assembly of printed parts 5.1 Wing assembly VL Pyörremyrsky Glue wing parts L1-L3 perfectly together. The new 3DLabPrint lock system will help you. Repeat for the right side. Glue both halves of the wing together. Use the CA glue, (position locks and wing pins will help you to align the parts), and use activator to speed up the glue curing.
- Page 16 You can use snap knife for cleaning the surface of printed parts, but mostly it is not necessary. Glue fuselage parts F1-F4 with CA glue together. The new 3DLabPrint lock system will help you. Zkontrolujte kolmost dílu F4 na uložení křídla dílů F1 a F2 před zalepením. Do not glue rudder part before tail and elevator assembly.
- Page 17 ... print your plane | www.3DLabPrint.com 5.2.2 Fuselage tail - elevator pushrods and servos Glue L1 and L2 parts of the stabilizer and elevator. The profile is symmetric, so the left and right sides are identical. Glue the stabilizers perfectly perpendicular to the fuselage. Assemble both sides of the elevator with the elevator control lever on a flat surface.
- Page 18 ... print your plane | www.3DLabPrint.com 6. Servo installation Cut loose the servo holder ears on aileron servos. Install the prepared servos to wing servo bays. Use a 1mm steel wire with Z bends as a linkage between the servos and aileron control horns.
- Page 19 ... print your plane | www.3DLabPrint.com 8. Painting/marking and Final assembly/setting See video guide #7 Refer to your R/C system userguide for setup information. See video guide #8 you will need: Your own Rx/Tx system Install your reciever, connect battery, setup servos and etc. with your trasmitter, check servo...
- Page 20 ... print your plane | www.3DLabPrint.com 10. Pilots Please Attention! For the first flights we recommend setting the center of gravity to around 5 mm forward of the CG tag - nose heavy, this increases the stability (you can use heavier battery). Increasing expo settings on your transmitter for elevator and ailerons to 80 % calms response from your stick inputs.
-
Page 21: Shopping List
... print your plane | www.3DLabPrint.com Shopping list Printing material: 0,25 kg of LW-PLA by ColorFabb a few of PLA or PETG (elevator arm, motor mount, spinner) R/C system, Tx (EU) (GLOBAL) + compatible Rx 4ch, or opt1 we use JETI...
