20
NOTE: The IGO Fold battery can be charged
with the battery box either installed on or
removed from the power base.
To charge the battery using the off-board charger:
1. Position the front of your power chair next to a
standard electrical outlet.
2. Be certain the controller power is turned off and
the freewheel levers are in the engaged position.
See "Your Power Chair."
3. Plug the off-board charger into the off-board
charger/programming socket of the controller.
See figure 12.
4. Plug the off-board charger into the electrical
outlet.
WARNING! The LED lights on the charger
indicate different charger conditions at
various times: charger power on and
charging complete. If the LED does not
indicate that charging is completed within
24 hours, unplug the charger from the
outlet and
retailer. Refer to the manual supplied with
the charger for a complete explanation of
these indicators.
5. When the battery is fully charged, unplug the off-
board charger from the electrical outlet and then
from the controller.
NOTE: The battery condition meter on your power chair controller displays an approximate reading
of battery strength. Refer to Table 1 for battery condition meter codes.
1st LED blinking
Table 1. Battery Condition Meter Codes
contact your authorized
LEDs
5
4
3
2
1
Figure 12. Battery Charging using the Off-board Charger
Battery Percentage
55-100% battery remaining
35-55% battery remaining
20-34% battery remaining
12-19% battery remaining
<12% battery remaining
<5% battery remaining
