Pride Mobility IGO Fold Owner's Manual page 41

8
1
Freewheel Lever
2.
Battery Box
3.
Anti-tip wheel
Figure 2. Power Base
Electrical Components
The electrical components are located on the power base. The main circuit breaker is located on the back
of the battery box, beneath the handle. See figure 2.
Controller Connector: This is where the controller connects to the power base. Each controller uses a
different type of cable. Regardless of which type of controller is used, the cable must be secured to the
assembly and not allowed to drag on the floor.
Battery Box Charger Port: This enables you to charge the battery when the battery box is removed from
the power base. See "Batteries and Charging."
IGO Fold
4. Light
5. Controller Charger Port Location
6. Battery Charger Port Location
7. Stand Wheel
