Veris Industries AG04 Installation Manual

Installation Guide

Accessories

NOTICE
• This product is not intended for life or safety applications.
• Do not install this product in hazardous or classi ed locations.
• Read and understand the instructions before installing this product.
• Turn o all power supplying equipment before working on it.
• The installer is responsible for conformance to all applicable codes.
If this product is used in a manner not speci ed by the manufacturer, the protection
provided by the product may be impaired. No responsibility is assumed by the
manufacturer for any consequences arising out of the use of this material.
Z207871-0A Page 1 of 2
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris 'V' logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Combination Carbon Monoxide and
Nitrogen Dioxide Sensing Element

Product Overview

The AG04 carbon monoxide (CO) and nitrogen dioxide (NO
GWNP Series (BACnet/Modbus Output) gas platform unit to provide accurate monitoring of CO and NO
Common sources of CO include automobile exhaust from gasoline engines, gasoline powered furnaces, gasoline
powered water heaters, and gasoline generators. Common sources of NO
engines and diesel powered generators. The sensor is calibrated at the factory, so no field calibration is needed. The
AG04 is warranted to meet accuracy specifications for two years after the date of manufacture.

Specifications

Measurement Range
Sensor Warranty
Low Level Setpoint
High Level Setpoint
Operating Temperature Range
Operating Humidity Range
Note: TheAG04 sensor works only with Veris GWNP (protocol output) Series gas platform devices. The AG04 will not work with
GWNM, GWNV or GWN1 versions of the GWN Series.
©2019 Veris Industries USA 800.354.8556 or +1.503.598.4564 / support@veris.com
Other companies' trademarks are hereby acknowledged to belong to their respective owners.
AG04
) sensing element is designed to work with the Veris
2
CO: Electrochemical
Sensor Type
NO2: Electrochemical
CO: 0 to 500 ppm
NO2: 0 to 20 ppm
CO: ±5% of range
Accuracy
NO2: ±5% of range
CO: 1 ppm
Resolution
NO2: 0.1 ppm
2 years from manufacture date
CO: 25 ppm (default)
NO2: 1 ppm (default)
CO: 180 ppm (default)
NO2: 3 ppm (default)
-20 to 40 °C (-4 to 104 °F)
0 to 90% RH non-condensing
levels.
2
include automobile exhaust from diesel
2
TM
0819
