Arkon GN033-SBH Quick Start Manual

TT223-G | Cup Holder Mount for TomTom® GPS
GN033-SBH
Cup Holder Mount
APTTV
Adapter plate for
TomTom VIA
Check Compatibility

Cup Holder Mounting

Step 1. Connect the gooseneck shaft (A) to the cup holder base (B) by
aligning the groove on the base to the ridge inside of the bottom
of the shaft.
(C) Thumb wheel
adjustment
knob
Step 2. Place the Universal Cup Holder Mount into the designated cup
holder in the vehicle. Adjust the thumb wheel adjuster (C) to open
or close the cup holder prongs to fit in the cup holder.
Step 3. For oversize cup holder openings or the adjustable "pop out" cup
holders use the optional self-adhesive side support pads (D). Install
the pads by removing the adhesive backing and placing it on the
flat surface side of the cup holder support leg.

Safety Precautions

!
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
APTTO
Adapter plate for
TomTom ONE
Check Compatibility
APTTOXL
Adapter plate for
TomTom ONE XL
and XL • S
Check Compatibility
APTTEP
Adapter Plate
for EasyPort
Check Compatibility
APTTGO520
Adapter plate for
TomTom GO x20, x30
Check Compatibility
Patent Pending
(A) Cup Holder
Neck
(B) Cup Holder Base

Package Contents:

(1) GN033-SBH - 5" Cup holder pedestal mount with flexible gooseneck shaft
(1) APTTO - Adapter plate for TomTom ONE™ Series
(1) APTTOXL - Adapter plate for TomTom ONE XL / XL • S™ Series
(1) APTTGO520 - Adapter plate for TomTom GO™ Series
(1) APTTEP - Adapter plate for TomTom EasyPort™ Series
(1) APTTSE - Adapter plate for TomTom Start™ and Ease™
Note: mount may not work with adjustable, "pop out" cup holders or
oversize cup holder openings found in full-size pickup trucks.

TomTom Device Compatibility:

TomTom VIA
TomTom ONE 125 125-SE (TomTom EasyPort Mount)
TomTom ONE 130, ONE 130-S (TomTom EasyPort Mount) TomTom ONE 140,
ONE 140-S (TomTom EasyPort Mount)
TomTom XL 325, XL 325-S, XL 325-SE (TomTom EasyPort Mount) TomTom XL
330, XL 330-S (TomTom EasyPort Mount)
TomTom XL 335 Series (TomTom EasyPort Mount)
TomTom XL 340, XL 340-S, XL 340 LIVE Series (TomTom EasyPort Mount)
TomTom XL 350 Series (TomTom EasyPort Mount)
TomTom XXL 530-S, XXL 535-T, XXL 540-S/W TE, XXL 550 Series (TomTom
EasyPort Mount)
TomTom ONE (US Edition, US 3rd Edition)
TomTom ONE XL (1st Edition) - TomTom ONE XL-S (1st Edition)
TomTom ONE 22, ONE 22 Regional, ONE 22 Regional Traffic
TomTom XL 22, XL 22 Regional (TomTom EasyPort Mount)
TomTom ONE UK / EUROPE (NEW Edition aka 2nd Edition, 3rd Edition)
TomTom GO 520 / 530 / 630 / 720 / 730 / 920 / 920T / 930
TomTom Start and Ease
Do not place mount in or near an air bag deployment zone or where it
!
will obstruct view of the road.
TomTom, ONE, GO, and EasyPort, Start and Ease are product names, trademarks, or registered trademarks
of TomTom International b.v. Arkon Resources, Inc. is not affi liated with TomTom International b.v.
(D) Optional
support
pads

TomTom ONE and ONE XL Adapter Plate Installation

Step 1. Slide the adapter plate up into the grooves on the
back of the TomTom ONE, ONE XL, or ONE XL • S.
The Mobile Mounting Specialists™
Consumer Hotline:
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in Taiwan and China
© Copyright 2011 Arkon Resources, Inc.
