Techno TH399 Installation Instructions

TH399
TH399
MINI
IP68 2bar
MADE IN ITALY
1
TH399 MINI
2-3 POLES
1
TH399
2-3-4-5-6
2+2-3+3
POLES
Techno s.r.l. Via Bancora e Rimoldi, 27 - 22070 Guanzate (CO) ITALY
tel +39 031 976445 fax +39 031 976680 web www.techno.it email info@techno.it
2
3
CH 24
2
3
CH 24
For further information please refer to product data sheet on our web-site www.techno.it
Ø 7.0 ÷ 9.0 mm
Ø 9.0 ÷ 13.5 mm
CH 29
Ø 7.0 ÷ 9.0 mm
Ø 9.0 ÷ 13.5 mm
ON REQUEST
BLIND HOLE
ADAPTER HOLE
Ø 9.0 mm
≤ Ø 7.0 mm
ON REQUEST
BLIND HOLE
ADAPTER HOLE
Ø 9.0 mm
≤ Ø 7.0 mm
Ø 8.0 ÷11.0 mm
Ø11.0 ÷ 17.0 mm
