- Page 1 Assembly instructions for TH387 Specifications of Torque Forces 16 March 2017 © Techno s.r.l. All rights reserved.
- Page 2 TH387 screw terminals tightening Screw tightening Cable cross-section THB.387.x2x.x 0.5 mm – 4.0 mm THB.387.x3x.x Stranded and solid THB.387.x4x.x conductors max. 0.8 Nm 0.25 mm – 2.5 mm THB.387.x5x.x max. 0.2 Nm Stranded and solid conductors © Techno Srl All rights reserved.
- Page 3 TH387 cable-to-cable (long cable gland) Cable gland Clockwise - 2.5 Nm 22 mm Matching the connectors • Turn the ferrule clockwise until fully seated (max. 1.0 Nm) • Also, it is enough to tighten until you notice firm resistance to rotation •...
- Page 4 TH387 cable-to-cable (short cable gland) Cable gland Clockwise - 2.5 Nm 22 mm Matching the connectors • Turn the ferrule clockwise until fully seated (max. 1.0 Nm) • Also, it is enough to tighten until you notice firm resistance to rotation •...
- Page 5 How to use the quick-fix spanner to be used for Code: THx.387.xxx.L Bottom Bottom to be used for Code: THx.387.xxx Other products (i.e. TH405) © Techno Srl All rights reserved.
- Page 6 2.0 Nm ÷ 2.5 Nm Important: the cable gland (B) will be tightened automatically when turning the nut (A) Cable retention and IP68 resistance are guaranteed (acc. to EN61984 and EN60998/EN60529) © Techno Srl All rights reserved.
- Page 7 TH387 panel-mounted M20 (non conductive panel) Important In order to hold the panel- connector when panel- Code: THx.387.Mxx mounting, you should insert the plug (or socket) connector into THx.387.Lxx the panel-socket (or panel-plug) connector. A specific assembly tool is available starting May ‘17 Fixing nut Clockwise - 1.5 Nm...
- Page 8 TH387 panel-mounted M20 (all panels) Code: THx.387.Nxx Important In case of circular hole, in order to hold THx.387.Pxx the panel-connector when panel- mounting, you should insert the plug (or socket) connector into the panel-socket (or panel-plug) connector. A specific assembly tool is available starting May ‘17...
- Page 9 TH387 panel-mounted M25 Code: THx.387.Fxx Important THx.387.Exx In case of circular hole, in order to hold the panel-connector when panel- mounting, you should insert the plug (or socket) connector into the panel-socket (or panel-plug) connector. A specific assembly tool is available starting May ‘17...
- Page 10 TH387 panel-mounted M25 Code: THx.387.Cxx Important THx.387.Dxx In case of circular hole, in order to hold the panel-connector when panel- mounting, you should insert the plug (or socket) connector into the panel-socket (or panel-plug) connector. A specific assembly tool is available starting May ‘17...
- Page 11 TH387 panel-mounted (all versions) Matching the connectors Turn the ferrule clockwise until fully seated (max. 1.0 Nm). Also, it is enough to tighten until you notice firm resistance to rotation The plug and socket will be matched correctly...
