1.

Introduction

The OneFlow Innovative Scale Control System provides
®
protection from hard scale formation on internal plumbing
surfaces. The OneFlow system is a single cartridge-based
®
system that must be installed on a cold water line prior to a
single water heating device (water heater or tankless water
heater) that requires protection from the ill effects of hard water.
OneFlow uses template assisted crystallization (T.A.C.) to
®
attract hardness minerals and convert them into harmless,
inactive microscopic crystal particles. These crystals stay
suspended in the water and are passed to drain. The system
requires very little maintenance, no backwashing, no salt and
no electricity. Typical hardness problems, especially build-up of
scale in heating elements, pipes, water heaters, boilers are no
longer a concern. OneFlow
®
need additional chemicals. It is a hard scale prevention device
with proven third party laboratory test data and years of suc-
cessful commercial, residential and foodservice applications.
OneFlow is the intelligent scale solution and is a great alterna-
®
tive to water softening or scale sequestering devices.
OFPSYS EU
• Reduces sediment, chlorine taste and odor
• OneFlow converts hardness minerals to harmless,
®
inactive microscopic crystals making OneFlow
alternative to water softeners
• Virtually maintenance free - No salt bags or other chemicals
required
• No energy consumption (different compared to other scale
control technologies)
• Contributes to reduce water and electric consumption, no
control valve needed
• Innovative technology with an enhanced respect of the
environment, salt free, without additional chemicals
• Improves efficiency of all water heating devices and down-
stream plumbing components
• Simple sizing & installation – standard 3/4" connections
• Perfect solution for homes where equipment protection
is desired for longer equipment life and reduced energy
consumption
• Inlet ball valve for easy isolation shutoff and filter changes
• OneFlow cartridge-based systems are easily maintained;
®
change the TAC cartridge once every two years
• Mounting bracket and wrench for cartridge change-outs
included
* Exceeding maximum flow can reduce effectiveness and void
warranty. Pressure drop at peak flow rate is less than 1 bar at
27°C feed water.
** This system is delivered with 3/4" MNPT x 3/4" MBSPT fit-
tings. The fitting marked with red should be connected to the
inlet/outlet of the system.
*** See more information on our website: www.watts-oneflow.com
The descriptions and photographs contained in this product specification sheet are supplied by way of information only and are not binding. Watts Industries reserves the right to carry out
any technical and design improvements to its products without prior notice. Warranty: All sales and contracts for sale are expressly conditioned on the buyer's assent to Watts terms and
conditions found on its website at www.wattswater.eu. Watts hereby objects to any term, different from or additional to Watts terms, contained in any buyer communication in any form,
unless agreed to in a writing signed by an officer of Watts.
OFPSYS EU_IOM_IT_W_UK_01_21_Rev0
is not a water softener. It does not
an effective
®
2.

System Specifications

Inlet/outlet connections: 3⁄4" FNPT with BSP threaded fittings
Nominal flow rate OFPSYS: up to 38l/min
Flow capacity (continuous flow rate): up to 38l/min, 24/7/365
for 2 years for the OFPSYS cartridge
Maximum pressure: 90psi / 6.2 bar
Maximum temperature: 38°C
Minimum temperature: 5°C
Capacity: Elements present in the water will gradually degrade
the effectiveness of the cartridge. Change the OPSYS cartridges
at least once every two years.
A OneFlow Innovative Scale Control system shall be installed on
®
the cold water service line to condition the tap water just prior to
the service line feeding the equipment it is designed to protect.
The system will be sized for maximum or peak flow rate based
on the specification of said equipment. A OneFlow
also be installed to protect multiple pieces of equipment from
the ill-effects of hard water scale provided the aggregate peak
flow rate for each piece of equipment it is protecting has been
considered. The system shall be plumbed with a bypass valve to
allow isolation of filter housing to allow the bypass of untreated
water in the event that service or cartridge replacement be nec-
essary. Bypass is recommended but not required. The installa-
tion area should be suitable in size for the housing to be serviced
without encumbrance. The OneFlow
additional water to backwash, flush, or regenerate once put into
service. The system shall not require any chemical additives and
shall not require electricity for operation.
2.1

Feed Water Chemistry Requirements

pH
Hardness (maximum)
Water Pressure
Temperature
Free Chlorine
Iron (maximum)
Manganese (maximum)
Copper
Oil & H2S
Total Phosphates
Silica (maximum)
TDS
All these water chemistry requirements are corresponding to
the average parameters of the water delivered usually, please
contact your water supplier or local autorities in order to con-
firm the compliance.
Watts Water Technologies, Inc.
system may
®
system does not require
®
6.5-8.5
427 mg/L CaCO3 (28,8°dH, 51,3°fH)*
1 bar - 6.2 bar
5°C - 38°C
<2 mg/l
0.3 mg/l**
0.05 mg/l**
1.3 mg/l***
Must be Removed
< 3.0 mg/l
20 mg/l
†
1500 mg/l
††
3
