- Page 1 Description and application guide WattsIndustries.com...
-
Page 2: Table Of Contents
5 BT-CT02 RF software update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 only and are not binding. Watts Industries reserves the right to carry out any technical and design improvements to its products without prior notice.”... - Page 3 Name Descriptive Applications Possible pairing Name Descriptive Applications Possible pairing BT-S6Z02 RF 6 zones extension module for Hydraulic heating and cooling BT-A02RF BT-A02 RF RF thermostat with knob Electrical heating BT-M6Z02 RF BT-M6Z02 RF (Water floor heating and cooling) BT-D02 RF Batteries power supply Hydraulic heating BT-FR02 RF...
-
Page 4: Systems
Systems 3.1 Hydraulic Systems with Central Unit NOTE: Following representative examples and configurations are applicable only if Central Unit BT-CT02 RF Software Version ≥ V.03.01 3.1.1 A thermostat (mono zone) managing a boiler (or a heat pump). Equipments: • 1 Thermostat BT-D02 RF (or BT-A02 or BT-DP02 RF) •... -
Page 5: Water Floor Heating (Mono Zone) Managing Hydraulic Circuit And A Boiler
3.1.2 Water floor heating (mono zone) managing hydraulic circuit and a boiler. Equipments: • 1 Thermostat BT-D02 RF (or BT-A02 or BT-DP02 RF) • 1 Wall Receiver BT-WR02 RF (or BT-FR02 RF) for driving an actuator • 1 Central Unit BT-CT02 RF •... -
Page 6: Hydraulic Radiator Valve (Multi Zones) Managing A Boiler (Or A Pump)
3.1.3 Hydraulic radiator valve (multi zones) managing a boiler (or a pump). Equipments: • 1 (or more) Thermostatic Head BT-TH02 RF • Option : BT-A02 RF or BT-D02 or BT-DP02 RF thermostats • 1 Central Unit BT-CT02 RF • 1 receiver BT-WR02 HC RF for driving a boiler or an heat pump (or a BT-WR02 RF for driving a pump) BT-CT02 RF For a correct installation, refer to dedicated user guides of each product, then:... -
Page 7: Water Floor Heating (Multi Zones) With Several Bt-M6Z02 Rf
BT-M6Z02 RF 3.1.4 Water floor heating (multi zones) with several BT-M6Z02 RF and pump management. Equipments: • 2 Connecting Boxes BT-M6Z02 RF • 2 (or more) Thermostats BT-D02 RF (or BT-A02 RF, or BT-DP02 RF) • 1 Central Unit BT-CT02 RF BT-CT02 RF •... -
Page 8: Water Floor Heating And Cooling (Multi Zones)
3.1.5 Water floor heating and cooling (multi zones). Equipments: BT-M6Z02 RF • 2 Connecting boxes BT-M6Z02 RF • 2 (or more) Thermostats BT-D02 RF (or BT-A02 RF, BT-DP02 RF, BT-D02 RH RF) ** • 1 Connecting box BT-HCM02 RF to drive the heating or cooling mode BT-HCM02 RT •... -
Page 9: Hydraulic Systems Without Central Unit
3.2 Hydraulic Systems without Central Unit 3.2.1 A thermostat (mono zone) managing a boiler or a heat pump. 3.2.2 Single circuit water floor heating, managing actuator and pump (boiler or heat pump). Equipments: Equipments: • 1 Thermostat BT-D02 RF (or BT-D02 or BT-DP02 RF) •... -
Page 10: Water Floor Heating (Only 1 Bt-M6Z02 Rf)
3.2.3 Water floor heating (only 1 BT-M6Z02 RF). Equipments: • 1 Connecting Box BT-M6Z02 RF • 1 Thermostat BT-D02 RF (or BT-A02 RF or BT-DP02 RF) BT-M6Z02 RF BT-D02 RF UP TO SIX For a correct installation, refer to dedicated user guides of each product, then: WIRING CONNECTION: •... - Page 11 3.2.4 Water floor heating (multi zones) with several BT-M6Z02 RF BT-M6Z02 RF and only 1 boiler. Equipments: • 2 Connecting Boxes BT-M6Z02 RF • 2 Thermostats BT-D02 RF (or BT-A02 RF or BT-DP02 RF) BT-D02 RF UP TO SIX For a correct installation, refer to dedicated user guides of each produc floor WIRING CONNECTION: •...
-
Page 12: Water Floor Heating (Multi Zones) With Several Bt-M6Z02 Rf And Only 1 Boiler
3.2.5 Water floor heating (multi zones) with several BT-M6Z02 RF and only 1 boiler. BT-HCM02 RF Equipments: • 2 Connecting Boxes BT-M6Z02 RF • 2 (or more) Thermostats BT-D02RF (or BT-A/DP02RF or BT-D/DP02 RH RF ) ** • 1 Connecting box BT-HCM02 RF to drive the heating or cooling mode For a correct installation, refer to dedicated user guides of each product, then: For a correct installation, refer to dedicated user guides of each product, then: For a correct installation, refer to dedicated user guides of each product, then:... -
Page 13: Electrical Heating Systems
3.3 Electrical heating System 3.3.1 One (or several) electrical heaters in multi zones with centralized remote control. Equipments: • 1 (or more) Thermostat BT-D02 RF (or BT-A02 RF or BT-DP02 RF) BT-D02 RF • Several receivers : BT-FR02 RF, BT-PR02 RF or BT-WR02 RF •... -
Page 14: One (Or Several) Electrical Heaters (1 Zone)
3.3.2 One (or several) electrical heaters (1 zone). Equipments: • 1 Thermostat BT-D02 RF (or BT-A02 RF or BT-DP02 RF) • Several Receivers: BT-FR02 RF, BT-PR02 RF or BT-WR02 RF BT-PR02 RF BT-WR02 HC RF For a correct installation, refer to dedicated user guides of each product, then: WIRING CONNECTION: For a correct installation, refer to dedicated user guides of each product, then: •... -
Page 15: Water Floor Heating And Hydraulic Radiator
3.4 Mixed System - combining several modes of heating with centralized remote control BT-M6Z02 RF 3.4.1 Water floor heating and hydraulic radiator. For a correct installation, refer to dedicated user guides of each product, then: Equipments: WIRING CONNECTION: • Connecting Box BT-M6Z02 RF •... -
Page 16: Water Floor Heating, Hydraulic Radiator And Electrical Heaters
3.4.2 Water floor heating, hydraulic radiator and electrical heaters. ZONE 1 Equipments: BT-M6Z02 RF • Connecting Box BT-M6Z02 RF Option • Thermostats BT-D02 RF (or BT-A02 RF, BT-DP02 RF, BT-D02 RH RF, BT-DP02 RH RF) • Central Unit BT-CT02 RF •... -
Page 17: System Limitations
Except the installation configuration, all the functions of the Central Unit are available on: • The web site www.wattswater.eu • On Watts Vision application available on Apple store (iOS) • On Watts Vision application available on Play store (Android) The remote control configuration should be performed in 3 steps after configuration of you heating and cooling system. -
Page 18: Problems And Solutions
No connection on Wifi network. 1. Check that you have the last software on the central unit, Wifi central unit and Pairing failure between the 1. Check compatibility: only Watts Vision devices are compatibles. Status 0/2. update available on www.wattswater.eu if needed. any devices device and the central unit update available on www.wattswater.eu if needed. - Page 19 Sede legale: Frazione Gardolo, Via Vienna, 3 - 38121 Trento (TN), Italia - Cod. Fisc. 00743720153 - Partita IVA n° IT 01742290214 Società unipersonale del gruppo Watts Italy Holding Srl - soggetta a direzione e coordinamento ai sensi degli artt. 2497 e s.m.i. del C.C.
