VIBIA Wind Assembly Instructions page 3

1
st
1
B
r d
3
2
A
3
rd
3
B
st
1
4
Maintenance
-Use a slightly-wet cotton cloth for cleaning.
-In case of malfunction or damage, please contact the retailer who sold the lamp.
ASSEMBLY INSTRUCTIONS
C
nd
D
2
A
C
nd D
2
A
E
F
NOTE: Please, follow these instructions just in case you need to fix the lamp to the ground. If you
do not need it to be fixed to the ground, skip steps 1 through 3 and go directly to step 4.
1. Disassemble the base (A) as follows:
Remove the two screws (B) using the supplied Allen wrench.
Hold the lamp (C) firmly and move it toward the cable (as shown by the arrow) until it comes
loose from the fixing plate (D).
Pull upwards to completely release it from the base (A)
Important: Do not do this if the lamp is leaning or lying on the ground. It must be vertical.
2. Fix the base (A) to the ground using the most adequate screws and plugs (not supplied).
3. Replace the lamp (C) following the instruction of step 1 backwards, making sure the lamp is
firmly joined to the anchorage device (D), and fix it in place by tightening the screw (B) with
supplied allen key.
4. After installing the fluorescent bulb, fix the shade (E) in place using its 4 screws (F) (supllied in
a bag), using the supplied Allen wrench.
