De Agostini Model Space T-72 Manual

№11 scale 1:16
Hide thumbs Also See for Model Space T-72:

Advertisement

Quick Links

Download this manual
BUILD AND DRIVE THE RADIO-CONTROLLED MODEL
№ 11
SCALE 1:16

Advertisement

loading
Need help?

Need help?

Do you have a question about the Model Space T-72 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for De Agostini Model Space T-72

Summary of Contents for De Agostini Model Space T-72

  • Page 1 BUILD AND DRIVE THE RADIO-CONTROLLED MODEL № 11 SCALE 1:16...
  • Page 2 Editorial and design by Continuo Creative, 39-41 North Road, London N7 9DP. Published in the UK by De Agostini UK Ltd, Battersea Studios 2, 82 Silverthorne Road, London SW8 3HE. Published in the USA by De Agostini Publishing USA, Inc.,121 E. Calhoun Street, Woodstock, IL 60098.
  • Page 3 T-72 TANK: STAGE THE DIORAMA LED BOX With this stage, you receive the final part of the diorama – the LED box, which illuminates when ‘hit’ by the tank. When turned on, the four LEDs should light up, indicating that the diorama is ready for operation. When fired on by the tank, the LEDs should light up in turn, and the speaker should play back an explosion sound.
  • Page 4 Connect the diorama speaker to the LED Then fit both parts together, as shown, Place the building front onto the assembly, box, by joining their wires together. positioning the wires in the space between and fix the parts together with the six the two parts.
  • Page 5 T-72 TANK: STAGE TURRET ROTATOR MOTOR With this stage, you receive the motor that will allow your tank turret to rotate through 270° (135° to the right and 135° to the left). PARTS 1. Screws (3 pcs.) 2. Turret rotator motor For this stage, you will need the parts supplied, plus the turret, the hull and a screwdriver.
  • Page 6 Remove the temporarily fitted turret base, Place the bottom of the turret through the Now fit the turret base back into position. as shown. hole in the centre of the hull, leading the This will hold the turret on the hull. wires through first.
  • Page 7 T-72 TANK: STAGE DRIVE MOTOR With this stage, you receive the first of the two motors that will power the tank’s transmission system. PARTS 1. Drive motor 2. Screws (2 pcs.) For this stage, you will need the parts supplied, plus the lower hull assembly, a road wheel set (Stage 16) and a screwdriver.
  • Page 8 Locate the two circled holes in the end of Then half-tighten the second screw into the Fit the spring into the next hole, then the motor, and half-tighten one of the two second hole. place the suspension bar over it, turning it screws into one of the holes.

  • Page 9: Transmission Assembly

    T-72 TANK: STAGE TRANSMISSION ASSEMBLY With this stage, you receive the first of two transmission assemblies, which will transmit the torque from the engine to the wheels, driving the tracks and therefore the tank. PARTS For this stage, you will need the parts received, the lower hull assembly, a road wheel set (Stage 18), the two brackets (Stages 10 and 29) and a screwdriver.
  • Page 10 Place both parts of the wheel onto the bar Pass the axle at the rear of the transmission Tighten one of the screws into the and secure them with a washer screw. Then assembly through the hole in the side of the indicated hole in the base of the press the hub cap into place.
  • Page 11 T-72 TANK: STAGE THE LOWER HULL With this stage, you receive the lower hull, as well as some fittings needed for other parts. The lower hull is made of strong plastic, specifically designed to be tough and durable. For now, you will be fitting the second idler wheel and the rollers. PARTS 1.
  • Page 12 Place a washer onto the axle bolt in the Remove the washer, and pass the bolt Place the washer onto the bolt, followed by centre of the idler wheel to check that it fits. through the hole at the front of the hull. the split washer.
