Bonnell Acoustic Puzzle Wall
ACU064
Package Contents
Acoustic Puzzle panels
(panels ship in packs of 10)
© UPLIFT Desk • 800-349-3839 • info@upliftdesk.com • upliftdesk.com
14.5'' from ear to ear
Step 1
Align two panels as shown, with the long slots in the center of
the panels facing each other. Slide the long slots together as far
as possible so that the top and bottom edges of both panels
are flush with each other.
This will form the first "X-shape" of your acoustic puzzle wall.
Step 2
Using two more panels, make a second X-shape, but this time
do NOT slide the panels all the way together. Instead, slide
them only about 2/3 of the way together and go to Step 3.
Step 3
Align the two indicated outer ears of the X-shapes as shown.
Once the slots are in line with each other, slide them together
so that the top and bottom edges of those panels are flush
with each other.
