StreetStrider 8s Owner's Manual page 7

# DESCRIPTION
21 Front wheel rim and tire
22 Front wheel hub
23 Steering linkage
Crank arm set with quick
24 release left side
Bottom bracket
25 Chain ring with guard
26 Chain
27 Rear wheel rim and tire
28 Internal gear hub
29 Front disc brake
Steering knuckle w/
30
lean stop
King pin bolt in front beam
31
clevis
32 Front disc rotor
33 Rear disc brake
34 Rear disc rotor
35 Rear drop out
Specification
Key
TERMINOLOGY: The right and left sides of the StreetStrider refer to sides when one is striding.
IMPORTANT: Save the box and packing material as they must be used to repack the StreetStrider for any returns.
Copyright © 2019 StreetStrider International, LLC
HARDWARE
Rim 36H, Tire 16" x 1 3/8", ISO 37 x 349
19 mm hex axle nut M12 x P1.75 x L10 x W19, nylon lock
Inboard and outboard M8 x P1.25 x L20 x W14 flats on stud
rod ends M8 x P1.25 x L10 x W13 nylon lock nut
Threaded linkage rod M8 x P1.25 x L20 rod, right and left thread ends
M8 x P1.25 x L5 x W14, right and left jam nuts
8 mm hex screw M8 x P1.0 x L15 x H12 x W8, 18 mm flange
QR stem M10 x P1.5 x L10 x W17, nylon lock
Square taper 68 x 122 mm
52 T
1/2" x 1/8" x 93 links
Rim 36 H, Tire 20" x 1 3/8", ISO 37 x 451
15 mm axle nuts 8 speed, 3/8" x 26 TPI x W15 axle nuts
5 mm hex mount screw M6 x P1.0 x L15 x H10 x W5, through knuckle
5 mm hex caliper screw M6 x P1.0 x L15 x H10 x W5, through bracket
5 mm hex outer pad W5 outer pad adjuster with 2 mm lock set screw
3 mm hex inner pad W3 inner pad adjuster, through center screw hole
Cable housing adjuster M6 x P1.0 x L15 knurled for fingers with lock ring
4 mm hex cable clamp M5 x P0.8 x L12 x H10 x W4, socket and nut
5 mm hex screw M6 x P1.0 x L15 x H10 x W5, socket screw
W10 nylon lock nut
Lean stop disc OD24 x T4 with 6 mm offset hole
Composite bushing OD12 x ID10 x L15 x 17 mm flange
8 mm hex bolt M10 x P1.5 x L75 x H15 x W8, socket
washer OD16 x ID10 x T1
17 mm nut M10 x P1.5 x L10 x W17, nylon lock
4 mm hex screw M5 x P0.8 x L10 x H10 x W4, Rotor 120 mm
5 mm hex mount screw M6 x P1.0 x L15 x H10 x W5, through drop out
5 mm hex caliper screw M6 x P1.0 x L15 x H10 x W5, through bracket
5 mm hex outer pad W5 outer pad adjuster with 2 mm lock set screw
3 mm hex inner pad W3 inner pad adjuster, through center screw hole
Cable housing adjuster M6 x P1.0 x L15 knurled for fingers with lock ring
4 mm hex cable clamp M5 x P0.8 x L12 x H10 x W4, socket and nut
4 mm hex screw M5 x P0.8 x L10 x H10 x W4, Rotor 140 mm
Dropout slot for rear hub axle
Holes for rear brake mounting bracket
M5 x P0.8 hole for rear luggage rack screw
M=OD of threads, mm
P=pitch, threads/mm
SPECIFICATIONS
L=length W=wrench fit, mm
H=OD of head T=washer thickness, mm
QTY STATE
2 80-85 psi
2 Tighten
Lubricate balls
4 Tighten
2 Tighten
4 Tighten
2 Tighten
1 Snug
1 Tighten
1
1 Lubricate
1 80-85 psi
2 Tighten
4 Tighten
4 Adjust-tighten
2 Adjust-tighten
2 Adjust
2 Adjust-lock
2 Adjust-tighten
2 Adjust-tighten
4 Grease
2
Snug but allow
4
knuckle swivel
2
12 Tighten
2 Tighten
2 Adjust-tighten
1 Adjust-tighten
1 Adjust
1 Adjust-lock
1 Adjust-tighten
6 Tighten
2
4
2
7
