AppendixC

Cubase

Mackie Control mode function table (Nuendo/Cubase - PVC Overlay)
Controller
Channel Strip
Encoder 1 - 8 (Rotate)
Use with button Pan, EQ, Inserts,
Master, FX Sen & Por drive Ⅲ
Encoder 1 - 8 (Enter)
Use with button Pan, EQ, Inserts,
Master, FX Sen & Por drive Ⅲ
Fader 1-8
Fader M
Button "(Explorer)" 1-8
Button "M" 1-8
Button "S" 1-8
Button "(dot)" 1-8
Channel and fader control
Button "Motor"
Button "Lock"
Button "Flip"
Button "Track <"
Button "Track >"
Button "Bank <"
Button "Bank >"
Transport
Button "(Loop)"
Button "<<"
Button ">>"
Button "(Stop)"
Button "(Play)"
Button "(Rec)"
User define function
Button "Shift" (Use with F1-F8
buttons)
Button "F1-F8"
Assignment
Button "Pan" (Use with 1-8
encoders)
Button "EQ" (Use with 1-8
encoders)
Button "Inserts" (Use with 1-8
encoders)
Button "Master" (Use with 1-8
encoders)
Button "FX Send" (Use with 1-8
encoders)
Button "Por drive Ⅲ i" (Use with 1-8
encoders)
104
Adjust parameters of channel 1-8 according to selected function
(Pan, EQ, Inserts, Master, FX Send & Por drive Ⅲ )
Press the desired function and rotate the channel knob
Adjust parameters of channel 1-8 according to selected function
(Pan, EQ, Inserts, Master, FX Sen & Por drive Ⅲ )
Press the desired function and press the channel knob
Adjusting correspodance channel volume
Adjusting Master channel volume
Select track correspondently
Activate/inactivate "Mute" function of the correspondance track
Activate/inactivate "Solo" function of the correspondance track
Activate/inactivate "Record" function of the correspondance track
Lock all the faders
Swap the control for the faders and the rotary encoder knobs
Shift one channel up for all the faders except the master fader
Shift one channel down for all the faders except the master fader
Shift eight channel up for all the faders except the master fader
Shift eight channel down for all the faders except the master fader
Activate the loop function
Activate the rewind function
Activate the fast forward function
Activate the stop function
Activate the play function
Activate the record function
Press to use F1-F8 buttons as F9-F16 correspondently
Self define function
Please refer to "Encoder 1-8 (Rotate & Enter)"
Please refer to "Encoder 1-8 (Rotate & Enter)"
Please refer to "Encoder 1-8 (Rotate & Enter)"
Please refer to "Encoder 1-8 (Rotate & Enter)"
Please refer to "Encoder 1-8 (Rotate & Enter)"
Please refer to "Encoder 1-8 (Rotate & Enter)"
Function
