Logic Pro X - ICON PLATFORM NANO User Manual

Button"Page Up <<"
Button "Page Down>>"
Window control
Button "Mixer"
Utilities
Button "Edit"
Button "Undo"
Button "Redo"
Button "Save"
Button "Punch"
Button "Left"
Button "Right"
Marker controls
Button "Prev."
Button "Add"
Button "Next"
Automation
Button "Read"
Button "Write"
Navigation
Jog wheel (Rotate)
Button L/R
Button Up/Down
Buttons "Zoom" + "L/R"
Buttons "Zoom" + "Up/Down"

Logic Pro X

Mackie Control mode function table (Logic Pro)
Controller
Channel Strip
"Encoder 1 - 8 (Rotate)
Use with button Track, Pan/Surround,
EQ, Send, Plug-in & Inst."
"Encoder 1 - 8 (Enter)
Use with button Track, Pan/Surround,
EQ, Send, Plug-in & Inst."
Fader 1-8
Fader M
Button "(Explorer)" 1-8
Button "M" 1-8
Button "S" 1-8
Button "(dot)" 1-8
Channel and fader control
Button "Lock"
Button "Flip"
Button "Track <"
Button "Track >"
Flip page backward for the above functions
Flip page forward for the above functions
Switch to mixer window
Activate the edit function to edit the track
Activate the undo function to undo the last command
Activate the redo function to redo the last command
Activate the save function
Activate the punch function
Jump to the left most of a loop
Jump to the far right of a loop
Jump to previous marker point from the current position
Add a marker point at the current position
Jump to next marker point from the current position
Activate the read function for automation
Activate the write function to write a automation track
Scrolling the play-line forward & backward
Selecting between tracks
Selecting track vertically
Zoom in/out track horizontally
Zoom in/out track vertically
Adjust parameters of channel 1-8 according to selected
function (Track, Pan/Surround, EQ, Send, Plug-in & Inst)
Adjust parameters of channel 1-8 according to selected
function (Track, Pan/Surround, EQ, Send, Plug-in & Inst)
Adjusting correspodance channel volume
Adjusting Master channel volume
Select track correspondently
Activate/inactivate "Mute" function of the correspondance track
Activate/inactivate "Solo" function of the correspondance track
Activate/inactivate "Record" function of the correspondance
track
Lock all the faders
Swap the control for the faders and the rotary encoder knobs
Shift one channel up for all the faders except the master fader
Shift one channel down for all the faders except the master
fader
Function
