Keysight E8257D/67D PSG Signal
Generators Add Option 1ED
(Type-N Connector)
Kit Part Numbers:
E8251-60386 - For Front RF Output
E8251-60396 - For Rear RF Output
Notice: This document contains references to Agilent.
Please note that Agilent's Test and Measurement busi-
ness has become Keysight Technologies. For more in-
formation, go to www.keysight.com.
Installation Note
Part Number: E8251-90386
Printed in USA August 2014
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Keysight E8251-60386
Summary of Contents for Keysight E8251-60386
- Page 1 E8251-60386 - For Front RF Output E8251-60396 - For Rear RF Output Notice: This document contains references to Agilent. Please note that Agilent’s Test and Measurement busi- ness has become Keysight Technologies. For more in- formation, go to www.keysight.com. Installation Note Part Number: E8251-90386...
- Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 Add Option 1ED (Type-N Connector) Kit Part Numbers: E8251-60386 and E8251-60396 Product Affected: ......E8257D/67D Serial Numbers: ......
- Page 4 Installation Kit Parts List Table 1 E8251-60386, RF Front Output Item Quantity Description Part Number Installation Note E8251-90386 Type-N Connector Assembly E8251-60106 Table 2 E8251-60396, RF Rear Output Item Quantity Description Part Number Installation Note E8251-90386 Type-N Connector Assembly E8251-60107 Tools Required •...
- Page 5 Safety Considerations Before you disassemble the signal generator, turn the power switch off WARNING and unplug the power cord. Failure to unplug the signal generator can result in personal injury. Electrostatic discharge (ESD) can damage or destroy electronic components. All CAUTION work on electronic assemblies should be performed at a static-safe workstation.
- Page 6 Remove the Outer and Inner Signal Generator Covers Remove the Outer Cover Refer to Figure 1. Disconnect the power cord. 2. Using a T-20 driver, loosen the two screws (1) and remove the strap handle (2). 3. Using a T-15 driver, remove the center screws (3) on the four rear-panel feet (4). 4.
- Page 7 Figure 1 Outer Cover Removal...
- Page 8 Figure 2 Inner Top Cover Removal Remove Front Panel (Instruments with Front RF Output Connectors Only) Refer to Figure 3 1. Using the T-10 driver, remove the four screws from the Baseband Generator cover (E8267D only). 2. Using the T-15 driver, remove the six screws (1) from the sides of the frame. 3.
- Page 9 • W3 (LF OUTPUT) from the A11 Pulse/Analog Modulation Generator J403. • W4 ALC INPUT) from the A10 ALC J4. • W5 (PULSE/TRIGGER GATE INPUT) from the A11 Pulse/Analog Modulation Generator J201. • W6 (PULSE VIDEO OUTPUT) from the A11 Pulse/Analog Modulation Generator J203. •...
- Page 10 Install Option 1ED (Instruments with Front RF Output Connectors) 1. Using the 5/6” open-wrench, remove the semi-rigid cable connected to the RF output connector. 2. Using the T-10 driver, remove the screw securing the connector to the instrument. The screw is on the outside edge of the connector.
